Denon AVR-1611 Service Manual

123
PCB 5CH_AMP ASS'Y (1611E2,1611E1C,1621E1C,591E3,591EA model)
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q401 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q403 00D2710318909 TR 2SA 2N5401S J520254010010S
Q404 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q405 00D2710318909 TR 2SA 2N5401S J520254010010S
Q406 00D2730479909 TR 2SC 2N5551S J522255510010S
Q407,408 00D9600196302 TR KTA1268BL J5001268B0050S
Q409 963219003340S TR 2SC KTC3964 J502396400010S
Q410 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q412 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q413 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q415 00D2710318909 TR 2SA 2N5401S J520254010010S
Q416 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q417 00D9600196302 TR KTA1268BL J5001268B0050S
Q418 00D2730479909 TR 2SC 2N5551S J522255510010S
Q419,420 00D9600196302 TR KTA1268BL J5001268B0050S
Q421 963219003340S TR 2SC KTC3964 J502396400010S
Q422 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q424 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q425 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q427 00D2710318909 TR 2SA 2N5401S J520254010010S
Q428 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q430 00D2730479909 TR 2SC 2N5551S J522255510010S
Q431,432 00D9600196302 TR KTA1268BL J5001268B0050S
Q433 963219003340S TR 2SC KTC3964 J502396400010S
Q434 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q436 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q437 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q439 00D2710318909 TR 2SA 2N5401S J520254010010S
Q440 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q442 00D2730479909 TR 2SC 2N5551S J522255510010S
Q443,444 00D9600196302 TR KTA1268BL J5001268B0050S
Q445 963219003340S TR 2SC KTC3964 J502396400010S
Q446 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q448 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
Q449 00D2710314903 TR 2SA KTA1024Y J5001024Y0050S
Q451 00D2710318909 TR 2SA 2N5401S J520254010010S
Q452 00D9960018706 TR 2SD2390-Y J5032390Y0000S
Q454 00D2730479909 TR 2SC 2N5551S J522255510010S
Q455,456 00D9600196302 TR KTA1268BL J5001268B0050S
Q457 963219003340S TR 2SC KTC3964 J502396400010S
Q458 00D9960018706 TR 2SB1560-Y J5011560Y0000S
Q460 00D2730471907 TR 2SC KTC3206Y J5023206Y0050S
D402-404 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D408-410 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D414-416 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D420-422 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D426-428 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD401 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
