Denon AVR-1611 Service Manual

124
Ref. No. Part No. Part Name Remarks Q'ty New
ZD402,403 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD404 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD405,406 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD407 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD408,409 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD410 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD411,412 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
ZD413 00D2760643983 D,ZENER MTZJ5.1A K06005R134520S
ZD414,415 00D9630047502 D,ZENER MTZJ3.3B K06003R344520S
RESISTORS GROUP
R404 nsp R,FIXED 1WJ-5.6K N113135656220S
R406 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R408 nsp R,FIXED 1WJ-5.6K N113135656220S
R415 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R424,425 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R430,431 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R434 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R439 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R441 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R443 nsp R,METAL FILM 47-J,1W C060047065060S
R445 nsp R,FIXED 1WJ-5.6K N113135656220S
R450 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R451 nsp R,FIXED 1WJ-5.6K N113135656220S
R458 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R467,468 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R474,475 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R478 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R483 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R485 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R487 nsp R,METAL FILM 47-J,1W C060047065060S
R489 nsp R,FIXED 1WJ-5.6K N113135656220S
R493 00D9630337908 R,METAL 33-J,1W FLAMERETARDANT C060033065050S
R494 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R495 nsp R,FIXED 1WJ-5.6K N113135656220S
R502 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R511,512 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R517,518 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R521 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R526 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R528 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R530 nsp R,METAL FILM 47-J,1W C060047065060S
R534 nsp R,FIXED 1WJ-5.6K N113135656220S
R537 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R538 nsp R,FIXED 1WJ-5.6K N113135656220S
R545 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R551 00D9639005639 R,METAL FILM 100-J,1W FLAMERETARDANT C060010165060S
R554,555 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R561,562 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R564 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R569 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R571 nsp R,METAL FILM 1.2K-J,1W C060012265050S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
