Denon AVR-1611 Service Manual

125
Ref. No. Part No. Part Name Remarks Q'ty New
R573 nsp R,METAL FILM 47-J,1W C060047065060S
R577 nsp R,FIXED 1WJ-5.6K N113135656220S
R580 963252004160S POSISTOR 18BC471QB5RB F320184710050S
R581 nsp R,FIXED 1WJ-5.6K N113135656220S
R588 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R597,598 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R603,604 00D9630345903 R,FIXED 2WJ-0.47 FLAMERETARDANT N113136647820S
R607 nsp R,METAL FILM 3.3K-J,1W C060033265050S
R612 963125012630S R,METAL FILM 22-J,1W FLAMERETARDANT C060022065050S
R614 nsp R,METAL FILM 1.2K-J,1W C060012265050S
R616 nsp R,METAL FILM 47-J,1W C060047065060S
VR401-405 00D9630366407 VR,SEMI CARBON EVN-DCAA03B 1KB C541102315000S
CAPACITORS GROUP
C401 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C403 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C404 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C405 nsp C,CERAMIC 100PF-J/50V D010101167160S
C406 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C407 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C408 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C410 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C412 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C413 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C415,416 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C418 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C419 00D9630324005 C,ELECT 100UF-M/100V D04010108C240S
C420 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C421 nsp C,CERAMIC 100PF-J/50V D010101167160S
C422 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C423 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C424 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C426 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C428 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C429 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C431,432 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C434 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C436 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C437 nsp C,CERAMIC 100PF-J/50V D010101167160S
C438 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C439 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C440 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C442 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C444 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C445 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C447,448 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C450 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C452 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C453 nsp C,CERAMIC 100PF-J/50V D010101167160S
C454 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C455 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
