Denon AVR-1611 Service Manual

140
Ref. No. Part No. Part Name Remarks Q'ty New
Q2542 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2543 00D9600285006 TR KRC104S (ND) J522104S00210S
Q2549 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2550 00D9600285006 TR KRC104S (ND) J522104S00210S
Q2901 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2902 nsp SEMI KTA1504S J520015040150S
Q2903,2904 00D9630121509 TR KTC3875S J522038750210S
Q2905 nsp SEMI KTA1504S J520015040150S
Q2906-2910 00D9630121509 TR KTC3875S J522038750210S
Q3101 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q3102 00D9630328302 TR KTC3875G 1611E3 J5223875G0210S
Q3103 00D9630121402 TR KRA104S 1611E3 J520010400210S
Q3106-3109 00D9630121402 TR KRA104S J520010400210S
Q3110 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q3301 00D9630121509 TR KTC3875S J522038750210S
Q3302 00D9630120704 TR KRA102S(PB) J520010200210S
Q3303 963219002180S TR 2SD2114KT146W J5232114K0010S
Q3304 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q3305 00D9630121509 TR KTC3875S J522038750210S
Q3306 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D1502 963209010450S D,ESD VCH4AG100R8MAT K067040100080S *
D2501 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2502 00D9630328603 D,SCHOTTKY RB521S-30 K125521300010S
D3102 00D9630355401 D,SWITCHING KDS4148U 1611E3 K005041480030S
D3103 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D3107 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D3110 00D9630328603 D,SCHOTTKY RB521S-30 1611E3 K125521300010S
D3301 00D9630355401 D,SWITCHING KDS4148U K005041480030S
RESISTORS GROUP
R2906 nsp R,CHIP 33-J,1/16W 1611E2 C20003306M101S
R3119 nsp R,CHIP 10k-J,1/16W 1611E1C, 1621E1C C20001036M160S
R3119 nsp R,CHIP 3.3k-J,1/16W 591E3 C20003326M160S
R3119 nsp R,CHIP 18k-J,1/16W 591EA C20001836M160S
R3122 nsp R,CHIP 10k-J,1/16W 1611E2, 1611E1C C20001036M160S
R3122 nsp R,CHIP 22k-J,1/16W 1621E1C C20002234M161S
R3122 nsp R,CHIP 18k-J,1/16W 591E3 C20001836M160S
R3122 nsp R,CHIP 3.3k-J,1/16W 591EA C20003326M160S
CAPACITORS GROUP
C1001-1007 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1008 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C1009-1012 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1013,1014 nsp C,CERAMIC 12PF-J/50V D011120167101S
C1015,1016 nsp C,CERAMIC 15PF-J/50V D011150167101S
C1017 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1018 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1019 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1022-1029 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1037 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
