Denon AVR-1611 Service Manual

141
Ref. No. Part No. Part Name Remarks Q'ty New
C1039,1040 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1041 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1042 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1044,1045 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1047 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1055,1056 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1057 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1058 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1059 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1060 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1061 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1063 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1066-1070 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1073 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1075-1077 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1078 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1079 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1081,1082 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1083 nsp C,CERAMIC 0.082UF-K/16V D011823773161S
C1084 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1085 nsp C,CERAMIC 0.82UF-K/10V D011824772162S
C1086 nsp C,CERAMIC X7R0.039UF-K/50V D011393707160S
C1087 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C1088,1089 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1090 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1091-1093 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1094 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C1095 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1099 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1100 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1102,1103 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1105 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1107 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1109 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1122 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1124 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1125 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1127-1130 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1138 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1139 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1501 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1502 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1505-1508 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1509 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1512-1515 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1516 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1519,1520 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1521 nsp C,CERAMIC 10UF-K/16V D011106573200S
C1524-1526 nsp C,CERAMIC 1UF-K/10V D011105772161S
C1701-1703 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1706,1707 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C1708 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1709 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1710 nsp C,CERAMIC 1000PF-K/50V D011102177101S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
