Denon AVR-1611 Service Manual

142
Ref. No. Part No. Part Name Remarks Q'ty New
C1711-1713 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1714,1715 nsp C,CERAMIC 10PF-D/50V D011100117101S
C1716,1717 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1718 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1720 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C1721 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1722 nsp C,CERAMIC 0.022UF-K/25V D011223777160S
C1723-1728 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1901-1910 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1919-1941 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1942 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1943 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1944 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1945 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1948-1953 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1954 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1955-1960 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1961-1963 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C1965 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C1966,1967 nsp C,CERAMIC 7PF-C/50V D011070117101S
C1968-1981 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2101 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2103 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2105 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2106 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2107,2108 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2109-2128 nsp C,CERAMIC 1000PF-K/50V D011102177101S
C2129,2130 00D9630338606 C,ELECT 10UF-MVG/16V D050100083470S
C2131 nsp C,CERAMIC 0.1F-K/16V D011104177101S
C2132,2133 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C2135 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C2136 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C2137,2138 nsp C,CERAMIC X7R3900PF-K/50V D011392777160S
C2139 nsp C,CERAMIC X7R2700PF-K/50V D011272777160S
C2140-2142 nsp C,CERAMIC X7R3900PF-K/50V D011392777160S
C2143,2144 nsp C,CERAMIC X7R2700PF-K/50V D011272777160S
C2145-2160 nsp C,CERAMIC 470PF-J/50V D010471167160S
C2161,2162 963134000450S C,ELECT 100UF-MVG/16V D050101083660S
C2501-2503 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2513-2515 nsp C,CERAMIC 10UF-K/16V D011106573200S
C2516-2518 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C2519-2521 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2522-2527 nsp C,CERAMIC 10UF-K/16V D011106573200S
C2528-2530 nsp C,CERAMIC 15PF-J/50V D011150167101S
C2539-2544 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C2547-2552 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2553-2556 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2559 nsp C,CERAMIC X7R0.015UF-K/50V D011153777160S
C2560 00D9630325402 C,ELECT 470UF-MVG/6.3V D050471081200S
C2561,2562 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2564 nsp C,CERAMIC 1UF-K/10V D011105772161S
C2565,2566 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2569 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2572 nsp C,CERAMIC 1000PF-K/50V D011102177101S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
