Denon AVR-1611 Service Manual

143
Ref. No. Part No. Part Name Remarks Q'ty New
C2715-2724 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2725 nsp C,CERAMIC 470PF-K/50V D011471177101S
C2726 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2727 nsp C,CERAMIC 470PF-K/50V D011471177101S
C2728 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2729,2730 nsp C,CERAMIC 470PF-K/50V D011471177101S
C2901-2903 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2906-2908 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2909 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C2910 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C2911-2914 nsp C,CERAMIC 0.01UF-K/25V D011103774102S
C3101 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3102 nsp C,CERAMIC 1000PF-K/50V 1611E3 D011102177101S
C3103 nsp C,CERAMIC 0.1UF-K/16V 1611E3 D011104177101S
C3104 nsp C,CERAMIC 1000PF-K/50V 1611E3 D011102177101S
C3111-3113 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3114 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3120 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3121 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3122,3123 nsp C,CERAMIC 10PF-D/50V D011100117101S
C3124-3128 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3301,3302 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3303,3304 nsp C,CERAMIC T.C COG10PF-D/50V D010100117160S
C3305,3306 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3307 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C3315 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C3316 nsp C,CERAMIC 220PF-K/50V D011221177101S
C3317 nsp C,CERAMIC 0.1UF-K/50V D011104177101S
C9151-9155 nsp C,CERAMIC 1000PF-K/50V D011102177101S
OTHERS PARTS GROUP
L1001 nsp COIL,BEAD CBW160808U121T D340160811210S
L1501-1503 nsp COIL,CHIP FLC32C220K D307322205520S
L2501-2506 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2513-2515 nsp COIL,BEAD BLM21PG221SN1 D340201212210S
L2516 nsp COIL,BEAD CBW160808U121T D340160811210S
L2767,2768 nsp R,THICK 0-J,1/16W C20000006M160S
X1001,1002 141810044504S CRYSTAL CHIP FCX-04(28.63636MHz) E80528R636380S *
X1701 141810046500S CRYSTAL CHIP FCX-04(24.576MHz) E80524R576080S *
X1902 141810047503S CRYSTAL CHIP FCX-04(20.815MHz) E80520R815080S *
X3102 141810048506S CRYSTAL CHIP FCX-04(16MHz) E80516R000080S *
X3302 141810048506S CRYSTAL CHIP FCX-04(16MHz) E80516R000080S *
K1001-1004 644010108608S HDMI CONNECTOR(YKF45-7074N) L109100190450S *
K1501 644010108608S HDMI CONNECTOR(YKF45-7074N) L109100190450S *
K1702 00D9630237503 MODULE JSR1165-C E100116500040S
K1706 963643003580S TER,RCA 1PIN G600107C0020YS
K3101 00D9630294601 JACK,D3.5 EARPHONE G40100350000YS
K3102,3103 00D9630244703 JACK,D3.5 EARPHONE 1611E3 G40130802000YS
N2501 nsp CN.WAFER 5P L102050010040S *
N2701 nsp CN,WAFER 19P L109012521910S *

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
