Denon AVR-2311CI Service Manual

142
Ref.No. Part No. Part Name Remarks Q'ty New
27 - PCB SIRIUS
2311CIBKE3,2311BKE2,
2311SPE2,2311SPE1C
51 - PCB SIDE_CNT
52 - PCB REG
53 - PCB REG_CNT
57 - PCB FRONT_CNT
60 - PCB RS232
2311CIBKE3,2311BKE2,
2311SPE2,2311SPE1C
54A nsp PCB SPK ASSY 2311CIBKE3 7025HK0921011 1 *
54A nsp PCB SPK ASSY 891BKE3 7025HK0921021 1 *
54A nsp PCB SPK ASSY 2311BKE2 7025HK0921031 1 *
54A nsp PCB SPK ASSY 891BKEA 7025HK0921041 1 *
54A nsp PCB SPK ASSY 2311SPE1C 7025HK0921051 1 *
54A nsp PCB SPK ASSY 2311SPE2 7025HK0921061 1 *
54 - PCB SPK
55 - PCB SMPS
56 8U6331005900S PCB HDMI ASSY 2311CIBKE3 7025HK0921016 1 *
56 nsp PCB HDMI ASSY 2311BKE2 7025HK0921036 1 *
56 nsp PCB HDMI ASSY 2311SPE2 7025HK0921066 1 *
56 nsp PCB HDMI ASSY 2311SPE1C 7025HK0921056 1 *
56 8U6331006000S PCB HDMI ASSY 891BKE3 7025HK0921026 1 *
56 nsp PCB HDMI ASSY 891BKEA 7025HK0921046 1 *
1 963416010850D WINDOW DISPLAY 2311CIBKE3,891BKE3 5077212762090S 1 *
1 963416011670D WINDOW DISPLAY
2311BKE2,2311SPE2,
2311SPE1C,891BKEA
5077212762100S 1 *
2 963412000570D KNOB FUNCTION(KD) BK 5080211761000SZ 1
2 412510003031D KNOB FUNCTION SP 5087211901000S 1
3 00D9630362109 BADGE DENON BK 5630210028300S 1
3 00D9630362202 BADGE DENON SP 5630210028400S 1
4 963402009740D PANEL FRONT 2311CIBKE3 3067214911310S 1 *
4 963402009770D PANEL FRONT 2311BKE2 3067214911420S 1 *
4 963402009780D PANEL FRONT 2311SPE1C 3067214911530S 1 *
4 963402010040D PANEL FRONT 2311SPE2 3067214911520S 1 *
4 963402009750D PANEL FRONT 891BKE3 3067214921200S 1 *
NOTE :
Please change the destination-resistors when changing 2311BKCIBKE3 (8U6331005900S) to other destination.
Please refer to destination-resistors 134, 135, 136 page.
(SCHEMATIC DIAGRAMS : 32/36,33/36,34/36)
R4900(32/36
）
R4903(32/36
）
R5111(33/36) R5112(33/36) R5332(34/36) R5340(34/36)
2311BKE3 OPEN 10K OPEN 33 10K OPEN
2311BKE2 10K 4.7K 33 OPEN OPEN 10K
2311SPE2 10K 4.7K 33 OPEN OPEN 10K
2311SPE1C 10K 4.7K OPEN OPEN 10K 10K
d
NOTE :
Please change the destination-resistors when changing 891BKE3 (8U6331006000S) to other destination.
Please refer to destination-resistors 134, 135, 136 page.
(SCHEMATIC DIAGRAMS : 32/36,33/36,34/36)
R4900(32/36
）
R4903(32/36
）
R5111(33/36) R5112(33/36) R5332(34/36) R5340(34/36)
891BKE3 10K 4.7K OPEN 33 3.3K 18K
891BKEA 10K 4.7K OPEN OPEN 18K 3.3K
d
