Denon AVR-2311CI Service Manual

199
PCB HDMI ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U1001 234810018506S IC,LOGIC TC74VHC4052AFT J040744052080S
U1002 236810057606S IC,LOGIC ADV3002BSTZ J040300205510S
U1100 nsp IC ADV7840 J040784005510S
U1101 231810090509S IC PQ018ENA1ZPH J126018010030S
U1600 963142010720S OSC,CERAMIC 48MHz SMD2520 E85548R000020S *
U1601 nsp IC,LOGIC XC3S400A-4FGG320C J040340043230S
U1602 246810010604D IC IS42S32200E-6TL J001423220040S
U1603 963243010840S
IC MEMORY FLASH
(M25P40-VMN6TPB)
8952231100070 *
U1604 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U1605 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U1606 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U1607 231810071508S IC PQ012ENB1ZPH J126012010040S
U1800 00D2623436907 IC,LOGIC TC74VHC244FT J040742445530S
U1801 963239010410S IC ADV7511BSTZ-225 J040751100010S
U2000 231810090509S IC PQ018ENA1ZPH J126018010030S
U2001 nsp IC,LOGIC ADV7392 J045739200010S *
U2002 231310009508S IC PQ033DNA1ZPH J126033010010S
U2200 nsp IC ABT2015 J080201500020S *
U2201 00D2622557900 IC SN74LV14APWR J040741400180S
U2500 nsp IC K4T51163QI-HCE7 J001451163270S
U2501 nsp IC K4T51163QI-HCE7 J001451163270S
U2800 00D9630237503 MODULE JSR1165-C E100116500040S
U2801 00D9630237503 MODULE JSR1165-C E100116500040S
U2802 00D9630113009 MODULE JST1165 E100116500030S
U2803 00D2623077900 IC TC74VHCU04FT J040740405580S
U2805 236810062608S IC LC89058W-E J046890580020S
U3000 963243010830S
IC PAL/PLD
(EPM240T100C5N)
8952231100060 *
U3200 nsp IC ADSP21367KSWZ2A1181 J080213675520S
U3201 246810048609S IC W9864G2IH-6 J001986460060S *
U3202 963243010820S
IC MEMORY FLASH
(EN29LV160BB-70TIP)
8952231100050 *
U3802 236810086505S IC AK5358BET-E2 J043535805520S *
U3803 236810073509S IC AK4358VQ-L J042435800010S
U3804 00D2631289900 IC AZ4580M J121458000020S
U3805 00D2631289900 IC AZ4580M J121458000020S
U3806 00D2631289900 IC AZ4580M J121458000020S
U3807 00D2631289900 IC AZ4580M J121458000020S
U4400 963243010810S
IC MEMORY FLASH
(EN29LV160BT-70TIP)
8952231100040 *
U4401 963244012410S IS42S16400F-6TL J001421640060S
U4402 nsp IC MFI341S2164 J044341216410S
U4403 963239008830S IC TCC8600 32BIT J085860000010S
U4404 236810070500S IC AK4424ET-E2 TSSOP16 J042442405520S
U4405 00D2790055907 SW,POLY MICROSMD175F G300017500010S
U4600 231810069505S IC AOZ1021AI J048102100010S
U4601 nsp IC EX3AV J048030030010S *
U4602 nsp IC EX3AV J048030030010S *
U4604 nsp IC EX3AV J048030030010S *
U4605 nsp IC EX3AV J048030030010S *
NOTE :
When update Firmware,
please confi rm a last
version in SDI.
Use the service board
after updating it.
