Denon AVR-2311CI Service Manual

76
4. AUDIO
4.1. AUDIO CHECK
AUDIO OUTPUT : NG
Check ANALOG AUDIO BLOCK.
Check Digital AUDIO BLOCK.
Check via AD.
Check HDMI BLOCK.
Check other factors.
Check HDMI BLOCK.
Check Digital AUDIO BLOCK.
CHECK1
INPUT SURROND MODE SOURCE
ANALOG 2CH DIRECT ANALOG
CHECK2
INPUT SURROND MODE SOURCE
COAX or OPT --- Legacy(PCM or DolbyDigital or dts…)
CHECK4
INPUT SURROND MODE SOURCE
HDMI --- Legacy(PCM2ch or DolbyDigital or dts…)
CHECK6
Connect Setting SOURCE
HDMI OUT→other AVR HDMI IN CEC STANDBY
HD AUDIO
(PCM MULTI or DolbyTrueHD or dtsHD MA)
CHECK5
INPUT SURROND MODE SOURCE
HDMI ---
HD AUDIO
(PCM MULTI or DolbyTrueHD or dtsHD MA)
CHECK3
INPUT SURROND MODE SOURCE
ANALOG 2CH 7ch STEREO ANALOG
OK
OK
OK
OK
OK
NG
NG
OK (Digital Audio BOLCK is OK)
NG
NG
NG
NG
