Denon AVR-2311CI Service Manual

194
PCB VIDEO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
U2001 00D2622012908 IC,BU4052BCF-E2 J040405200060S
U2003 235810046603S IC,AVDM2000(NJW1327) J171132700010S *
U2004 231310009508S IC,PQ033DNA1ZPH J126033010010S
U2005 232810005504S IC BD7628F-E2 J127762800010S
U2007 232810005504S IC BD7628F-E2 J127762800010S
Q2001-2003 963219010750S TR 2SA KTA1504G J5201504G0210S *
Q2005 00D9630121606 TR KRC107S (NH) J522107S00210S
Q2006,2007 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2009-2011 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D1003,1004 963209003510S D,ESD CDS3C05HDMI1 K067030500010S
D2001-2003 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2005-2007 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D2009 00D9630328603 D,SCHOTTKY RB521S-30 K125521300010S
CAPACITORS GROUP
C1001-1003 nsp C,CERAMIC 10UF-K/10V D011106572200S
C1007-1009 nsp C,CERAMIC 10UF-K/10V D011106572200S
C2001,2002 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C2006-2008 00D9639006531 C,ELECT 22UF-M/16V D040220083070S *
C2009,2010 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C2013,2014 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C2017,2018 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C2019-2021 nsp C,CERAMIC 0.047UF-K/16V D011473773160S
C2023 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C2024,2025 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2027-2029 nsp C,CERAMIC 0.047UF-K/16V D011473773160S
C2031-2033 00D9630293602 C,ELECT 1UF-M/50V (Pb Free) D040010087150S
C2039-2041 nsp C,CERAMIC 0.047UF-K/16V D011473773160S
C2043,2044 nsp C,CERAMIC0.01UF-K/50V D011103777160S
C2045,2046 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2047 00D9639006531 C,ELECT 22UF-M/16V D040220083070S *
C2048-2050 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2051 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C2052 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2053 nsp C,CERAMIC1UF-K/16V D011105173161S
C2055,2056 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2058 nsp C,CERAMIC1UF-K/16V D011105173161S
C2059 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2060 00D9639006531 C,ELECT 22UF-M/16V D040220083070S *
C2061-2064 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2065 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C2066,2067 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2068 00D9639006531 C,ELECT 22UF-M/16V D040220083070S *
C2070,2071 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C2073 00D9639006531 C,ELECT 22UF-M/16V D040220083070S *
C2074 00D9639005862 C,ELECT 47UF-M/16V D040470083080S
C2079 nsp C,CERAMIC 220PF-J/50V D010221167160S
