Denon AVR-2311CI Service Manual

185
PCB SPK ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
z
IC100 963239010480S IC PC123X2YFZ (DIP4P SHARP) K614123000010S
z
IC102 231010091708S IC TOP258MG G200258000010S *
IC116 212050010508S IC KIA2431AP J126243118010S
Q1-5 00D9630120704 TR KRA102S(PB) J520010200210S
Q8-12 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
D1-5 00D9630355401 D,SWITCHING KDS4148U K005041480030S
D8 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D9,10 963209011740S D,RECTIFIER BRIDGE D3SB60-5000 K047036040030S
D100-102 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D103 203050018706S D,SCHOTTKY D25SC6M 60V 25A K120256000010S
D104-106 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D108 963209010430S
D,FAST RECOVERY AP01C-V1 52RE-AX K050000015000S
D109,110 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D112 00D2760401905 D,SWITCHING 1SS133T K000013300520S
ZD100 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD101 00D2760762958 D,ZENER MTZJ39B 2311CIE3, 891E3 K06039R044520S
ZD102 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD103 00D2760762958 D,ZENER MTZJ39B 2311CIE3, 891E3 K06039R044520S
ZD104 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD105 00D2760762958 D,ZENER MTZJ39B 2311CIE3, 891E3 K06039R044520S
ZD106,107 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD108,109 00D2760762958 D,ZENER MTZJ39B 2311CIE3, 891E3 K06039R044520S
ZD108,109 nsp R, CARBON FILM 1M-J, 1/5W 2311E2, 2311E1C, 891EA C00001056P520S
ZD110 963202010440S D,ZENER MTZJ22B 2311CIE3, 891E3 K06022R044520S
ZD110 00D2760762958 D,ZENER MTZJ39B 2311E2, 2311E1C, 891EA K06039R044520S
ZD111 nsp JUMPER (0.6/52MM) 2311CIE3, 891E3 L045084006040S
ZD111 00D2760762958 D,ZENER MTZJ39B 2311E2, 2311E1C, 891EA K06039R044520S
ZD112 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD113 nsp JUMPER (0.6/52MM) 2311CIE3, 891E3 L045084006040S
ZD113 00D2760762958 D,ZENER MTZJ39B 2311E2, 2311E1C, 891EA K06039R044520S
ZD114 00D9600095607 D,ZENER MTZJ5.6B K06005R644520S
ZD115 00D2760762958 D,ZENER MTZJ39B K06039R044520S
ZD116 nsp JUMPER (0.6/52MM) 2311CIE3, 891E3 L045084006040S
ZD116 00D2760762958 D,ZENER MTZJ39B 2311E2, 2311E1C, 891EA K06039R044520S
ZD117,118 963202010440S D,ZENER MTZJ22B K06022R044520S
ZD119 nsp JUMPER (0.6/52MM) 2311CIE3, 891E3 L045084006040S
ZD119 00D2760762958 D,ZENER MTZJ39B 2311E2, 2311E1C, 891EA K06039R044520S
RESISTORS GROUP
R5-18 963125010100S R,METAL FILM 10-J 2W C060010066050S
R28-33 00D9630310404 R,METAL FILM 2.2K-J,1W C060022265050S
R34 nsp R,METAL FILM 10K-J,1/4W C060103063050S
R35, 36 nsp R,METAL FILM 47K-J,1/4W
2311CIE3, 2311E1C, 891E3, 891EA C060047363050S
R35, 36 nsp R,METAL FILM 470K-J, 1/4W 2311E2 C060047463050S
R37,38 963125010110S R,METAL FILM 470-J,2W C060047166060S
R101, R104 nsp R,CARBON FILM 2.2M-J,1/5W 2311CIE3, 891E3 C00002256P520S
R105 nsp R,CARBON FILM 1M-J,1/5W 2311CIE3, 891E3 C00001056P520S
R114 nsp R,CHIP 270K-J,1/16W 2311CIE3, 891E3 C20002746M160S
R114 nsp R,CHIP 56K-J,1/16W 2311E2, 2311E1C, 891EA C20005636M160S
