Denon AVR-2311CI Service Manual

188
PCB REG_CNT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC1 00D2631289900 IC AZ4580M 2311CIE3 J121458000020S
IC103 00D2630553006 IC NJM7805FA J126780500130S
IC104 00D2630554005 IC NJM7905FA J126790500020S
IC105 00D2630553006 IC NJM7805FA J126780500130S
IC106 00D2630810008 IC NJM7808FA J126780800030S
IC107 00D2630503001 IC NJM7908FA J126790800020S
IC108 963239010770S IC NJM2388F09 2311E2, 2311E1C, 891E3, 891EA J126238800090S *
IC109 231310009508S IC PQ033DNA1ZPH 2311CIE3 J126033010010S
IC404 963239008800S IC ILX3232D 2311CIE3, 2311E2, 2311E1C J046323200020S
IC405 00D2631286903 IC PQ120DNA1ZPH 2311CIE3, 2311E2, 2311E1C J126120010010S
D114 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D115,116 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D117,118 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D119-121 00D2760401905 D,SWITCHING 1SS133T K000013300520S
D122 00D9630236504 D,SCHOTTKY RB721Q-40 K120072140010S
D123 00D2760401905 D,SWITCHING 1SS133T 2311E2, 2311E1C, 891E3, 891EA K000013300520S
D124-134 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D137-145 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD117,118 00D9600096004 D,ZENER MTZJ33B K06033R044520S
ZD401 00D2760665903 D,ZENER MTZJ16B 2311CIE3, 2311E2, 2311E1C K06016R044520S
RESISTORS GROUP
R37 nsp R,CHIP 100K-J, 1/16W 2311CIE3 C20001046M160S
R38 nsp R,CHIP 39K-J, 1/16W 2311CIE3 C20003936M160S
R39 nsp R,CHIP 15K-J, 1/16W 2311CIE3 C20001536M160S
R40, 41 nsp R,CHIP 39K-J, 1/16W 2311CIE3 C20003936M160S
R42-44 nsp R,CHIP 15K-J, 1/16W 2311CIE3 C20001536M160S
R45 nsp R,CHIP 39K-J, 1/16W 2311CIE3 C20003936M160S
R46 nsp R,CHIP 1K-J, 1/16W 2311CIE3 C20001026M160S
R47 nsp R,CARBON 100K-J, 1/5W 2311CIE3 C00001046P520S
R53, 54 nsp R,CHIP 0-J, 1/16W 2311CIE3 C20000006M160S
R453-456 nsp R,CHIP 1K-J, 1/16W 2311CIE3, 2311E2, 2311E1C C20001026M160S
CAPACITORS GROUP
C61 nsp C,CERAMIC 33PF-J/50V 2311CIE3 D010330167160S
C62, 63 00D9630234205 C,ELECT 10UF-M/50V 2311CIE3 D040100087070S
C64 nsp C,CERAMIC 33PF-J/50V 2311CIE3 D010330167160S
C65 nsp C,CERAMIC 0.1UF-K/50V 2311CIE3 D011104577160S
C66 nsp C,CERAMIC 1UF-K/16V 2311CIE3 D011105173161S
C67 nsp C,CERAMIC 33PF-J/50V 2311CIE3 D010330167160S
C68-70 00D9630234205 C,ELECT 10UF-M/50V 2311CIE3 D040100087070S
C71 nsp C,CERAMIC 0.1UF-K/50V 2311CIE3 D011104777200S
C72 nsp C,CERAMIC 33PF-J/50V 2311CIE3 D010330167160S
C73 nsp C,CERAMIC 1UF-K/16V 2311CIE3 D011105173161S
C74 nsp C,CERAMIC 0.1UF-K/50V 2311CIE3 D011104577160S
C75 00D9630234205 C,ELECT 10UF-M/50V 2311CIE3 D040100087070S
