Denon AVR-2311CI Service Manual

141
PARTS LIST OF EXPLODED VIEW
s
zParts for which "nsp" is indicated on this table cannot be supplied.
z
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
zPart indicated with the mark " ★ " is not illustrated in the exploded view.
zThe parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
2311CIE3 : U.S.A. & Canada model 2311E2 : Europe model 2311E1C : China model
891E3 : U.S.A. & Canada model 891EA : Australia model
BK : Black model SP : Premium Silver model
Ref.No. Part No. Part Name Remarks Q'ty New
22A nsp PCB FRONT ASSY 2311CIBKE3 7025HK0921013 1 *
22A nsp PCB FRONT ASSY 891BKE3 7025HK0921023 1 *
22A nsp PCB FRONT ASSY 2311BKE2 7025HK0921033 1 *
22A nsp PCB FRONT ASSY 891BKEA 7025HK0921043 1 *
22A nsp PCB FRONT ASSY 2311SPE1C 7025HK0921053 1 *
22A nsp PCB FRONT ASSY 2311SPE2 7025HK0921063 1 *
11 - PCB FUNCTION
14 - PCB H/P
21 - PCB USB
22 - PCB FRONT
23 - PDB FUNCTION_CNT
26 - PCB GUIDE_L
29 - PCB TOP_GUIDE
31 - PCB GUIDE_R
33 nsp PCB 7CH-AMP ASSY 2311CIBKE3 7025HK0921010 1 *
33 nsp PCB 7CH-AMP ASSY 891BKE3 7025HK0921020 1 *
33 nsp PCB 7CH-AMP ASSY 2311BKE2 7025HK0921030 1 *
33 nsp PCB 7CH-AMP ASSY 891BKEA 7025HK0921040 1 *
33 nsp PCB 7CH-AMP ASSY 2311SPE1C 7025HK0921050 1 *
33 nsp PCB 7CH-AMP ASSY 2311SPE2 7025HK0921060 1 *
59 nsp PCB VIDEO ASSY 2311CIBKE3 7025HK0921014 1 *
59 nsp PCB VIDEO ASSY 891BKE3 7025HK0921024 1 *
59 nsp PCB VIDEO ASSY 2311BKE2 7025HK0921034 1 *
59 nsp PCB VIDEO ASSY 891BKEA 7025HK0921044 1 *
59 nsp PCB VIDEO ASSY 2311SPE1C 7025HK0921054 1 *
59 nsp PCB VIDEO ASSY 2311SPE2 7025HK0921064 1 *
50A nsp PCB AUDIO ASSY 2311CIBKE3 7025HK0921015 1 *
50A nsp PCB AUDIO ASSY 891BKE3 7025HK0921025 1 *
50A nsp PCB AUDIO ASSY 2311BKE2 7025HK0921035 1 *
50A nsp PCB AUDIO ASSY 891BKEA 7025HK0921045 1 *
50A nsp PCB AUDIO ASSY 2311SPE1C 7025HK0921055 1 *
50A nsp PCB AUDIO ASSY 2311SPE2 7025HK0921065 1 *
50 PCB AUDIO
58 PCB PREOUT
53A nsp PCB REG_CNT ASSY 2311CIBKE3 7025HK0921012 1 *
53A nsp PCB REG_CNT ASSY 891BKE3 7025HK0921022 1 *
53A nsp PCB REG_CNT ASSY 2311BKE2 7025HK0921032 1 *
53A nsp PCB REG_CNT ASSY 891BKEA 7025HK0921042 1 *
53A nsp PCB REG_CNT ASSY 2311SPE1C 7025HK0921052 1 *
53A nsp PCB REG_CNT ASSY 2311SPE2 7025HK0921062 1 *
