Denon AVR-2311CI Service Manual

196
PCB AUDIO ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC3003 235810045600S IC R2A15220FP J084152200010S *
IC3005, 3006 00D2631289900 IC AZ4580M 2311CIE3, 2311E2, 2311E1C J121458000020S
IC3007 00D2623727904 IC, NJW1194A 2311CIE3, 2311E2, 2311E1C J084119400010S
IC3008 00D2631289900 IC AZ4580M 2311CIE3, 2311E2, 2311E1C J121458000020S
Q4001 00D9630044301 TR KTC2875B(MB) 2311CIE3, 2311E2, 2311E1C J5222875B0010S
Q4002, 4003 00D9630120704 TR KRA102S(PB) 2311CIE3, 2311E2, 2311E1C J520010200210S
Q4005 00D9630044301 TR KTC2875B(MB) 2311CIE3, 2311E2, 2311E1C J5222875B0010S
Q4006 00D9630120801 TR 2SC KRC102S (NB) 2311CIE3, 2311E2, 2311E1C J522010200210S
Q4026,4027 00D9630120704 TR KRA102S(PB) J520010200210S
Q4029 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4030 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4045 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4047 00D9630044301 TR KTC2875B(MB) J5222875B0010S
Q4048,4049 00D9630120704 TR KRA102S(PB) J520010200210S
Q4098,4099 963219010760S TR 2SC KRC231S(NW) 2311E2, 2311E1C, 891E3, 891EA J5220231M0010S *
Q4100 00D9630120801 TR 2SC KRC102S (NB) 2311E2, 2311E1C, 891E3, 891EA J522010200210S
Q4101 963219010740S TR 2SA KRA111S 2311E2, 2311E1C, 891E3, 891EA J520011100210S *
Q4102 00D9630120801 TR 2SC KRC102S (NB) 2311E2, 2311E1C, 891E3, 891EA J522010200210S
D3023 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D3025 00D9630328409 D,SWITCHING 1N4007 K000400700010S
D4000-4002 00D9630328409 D,SWITCHING 1N4007 K000400700010S
ZD4000 00D2760693962 D,ZENER 0.2W 3.6V UDZ
K06603R64P400S
CAPACITORS GROUP
C3001-3012 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3036,3037 00D9630234205 C,ELECT 10UF-M/50V D040100087070S
C3038,3039 00D9609009937 C,ELECT 100UF-M/50V D040101087060S *
C3042 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3047, 3048 nsp R,CHIP 0-J, 1/16W C20000006M160S
C3049 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3053 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C3056 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3058 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3059 00D9630333203 C,ELECT 100UF-M/16V D040101083090S
C3062 963134010710S C,ELECT 47UF-M/35V D040470085060S *
C3065 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3066,3067 963134010710S C,ELECT 47UF-M/35V D040470085060S *
C3068 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3072 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3073,3074 963134010710S C,ELECT 47UF-M/35V D040470085060S *
C3075 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3079 963134010710S C,ELECT 47UF-M/35V D040470085060S *
C3080 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3081, 3082 nsp R,CHIP 0-J, 1/16W C20000006M160S
C3083 nsp C,CERAMIC 330PF-J/50V D010331167160S
C3087,3088 nsp C,CERAMIC 330PF-J/50V D010331167160S
