Denon AVR-2311CI Service Manual

200
Ref. No. Part No. Part Name Remarks Q'ty New
U4606 231310009508S IC PQ033DNA1ZPH J126033010010S
U4607 231310009508S IC PQ033DNA1ZPH J126033010010S
U4608 234810015507S IC BU4248F J126424800010S
U5100 00MHC007805KZ IC TC74VHCT125AFT J040741255580S
U5101 963243010790S
IC MEMORY FLASH
(EN29LV160BB-70TIP)
8952231100020 *
U5102 234810014504S IC MC14094BDTR2G J040140940020S
U5103 00D2623437906 IC TC74VHCT244AFT J040742445540S
U5104 234810014504S IC MC14094BDTR2G J040140940020S
U5105 00D2623410907 IC TC74VHCT08AFT J040740800090S
U5106 234810014504S IC MC14094BDTR2G J040140940020S
U5107 234810014504S IC MC14094BDTR2G J040140940020S
U5108 00D2623444902 IC TC74VHC08FT J040740800280S
U5109 234810014504S IC MC14094BDTR2G J040140940020S
U5301 963243010780S
IC CPU MICRO PROCESS
(R5F64169DFD)
8952231100010 *
U5302 246810026500S IC R1EX24256ASAS0A J000242565550S
U5500 963243010800S
IC CPU MICRO PROCESS
(R5F3650KNFB)
8952231100030 *
Q1001-1003 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1004-1009 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1100-1102 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1103-1106 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1600 00D9600285006 TR KRC104S (ND) J522104S00210S
Q1601 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q1800 00D9630120704 TR KRA102S(PB) J520010200210S
Q1801 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q2000 00D9600285006 TR KRC104S (ND) J522104S00210S
Q2001 00D2750110905 SEMI HN1K02FU J543102000020S
Q2200 00D2750110905 SEMI HN1K02FU J543102000020S
Q2201 00D9600285006 TR KRC104S (ND) J522104S00210S
Q3200 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q3201 00D9630120704 TR KRA102S(PB) J520010200210S
Q4401,4402 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4403 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q4404 00D9630120704 TR KRA102S(PB) J520010200210S
Q4600 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4601 00D9600285006 TR KRC104S (ND) J522104S00210S
Q4602 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4603 00D9600285006 TR KRC104S (ND) J522104S00210S
Q4612-4619 00D9630121402 TR KRA104S J520010400210S
Q4620 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4621-4628 963219004200S CHIP FDC608PZ P-CH J543608000010S
Q4629-4631 00D2710326904 TR 2SA 2SA1954 J520195405510S
Q4632 00MHZ2000921Y CHIP DAN202U 1.2V K005020200200S
Q4633,4634 00D2710326904 TR 2SA 2SA1954 J520195405510S
Q4635,4636 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4638,4639 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4640 00D9630328302 TR 2SC KTC3875G(ALG) J5223875G0210S *
Q4643 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
Q4644 00D9600285006 TR KRC104S (ND) J522104S00210S
Q4645 00D9630120801 TR 2SC KRC102S (NB) J522010200210S
NOTE :
When update Firmware,
please confi rm a last
version in SDI.
Use the service board
after updating it.
