Denon AVR-2311CI Service Manual

18
Q0
OSD font data :
Upper
OSD DAT:
Lower
************
Q1
HD RADIO SDK/HD RADIO BBP (2311CIE3 only):
Upper
*HDSDK: **.**
Lower
*HDBBP:C0002.000
Q2
USB data :
Upper
USB :**.**
Lower
Q3
iPod Version :
Upper
iPod Dock:**.**
Lower
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Display order is
q
,
w
,
e
,
r
,
t
,
y
.
Condition State State
q
Sub-com NG No response from Sub-com
SUB ERROR 01
w
DIR NG No response from DIR
DIR ERROR 01
e
DSP NG
When DSP boot, executing DSP reset makes no change to DSP1 FLAG0
port "H".
DSP ERROR 01
No change to DSP FLAG0 port "H" before issuing DSP command.
DSP ERROR 02
When DSP data read, executing WRITE="L" makes no change to ACK="H".
DSP ERROR 03
When DSP data read, executing REQ="L" makes no change to ACK="L".
DSP ERROR 04
When DSP data write, executing WRITE="H" makes no change to ACK="H".
DSP ERROR 05
When DSP data write, executing REQ="L" makes no change to ACK="L".
DSP ERROR 06
When DSP special code boot, executing DSP reset makes no change to
DSP FLAG0 port "H".
DSP ERROR 11
No change to DSP FLAG0 port "H" before issuing DSP special read
command.
DSP ERROR 12
No change to DSP FLAG0 port "H" before DSP version read.
DSP ERROR 13
r
EEPROM NG Error appeared in EEPROM checksum.(*** is a block address number.)
E2PROM ERR***
t
USB NG No response from USB

-com.
USB ERROR 01
y
Both SUB/DSP
/EEPROM OK
(No error display, version display only)
