Denon AVR-2311CI Service Manual

3.5. Audio system confi rmation items
fi g.XX : Refer to the block diagram of the fi g.XXth.
Confi rmation item Setting and display Details of how to operate remote controller
Output sequence of remote control codes
※
It is useful to form a macro program.
Contents of confi rmation Remarks
1
Analog (signal) Path Input Mode : Fixed ANALOG
SURROUND mode : DIRECT
Amp assign : NORMAL
Display:
A01 DVD
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Analog / Output : Speakers (Front L/R)
·Input : Analog / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [7/PQRS]
e
KEY 7/PQRS (Main Zone)
Initialization & Amp assign NORMAL& Input
Mode Fixed ANALOG & SURROUND mode
DIRECT
8.Press [DVD]
r
DVD (Main Zone)
2
DIGITAL (signal) Path
(MAIN)
Input Mode : Fixed DIGITAL
Amp assign : NORMAL
Display:
A02 DVD
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (Front L/R)
·Input : Digital / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [8/TUV]
e
KEY 8/TUV (Main Zone)
Initialization & Amp assign NORMAL& Input
Mode Fixed DIGITAL
8.Press [DVD]
r
DVD (Main Zone)
3
DIGITAL (signal) Path
(ZONE2)
Input Mode : Fixed DIGITAL
Amp assign : ZONE2
ZONE2 Function : Source
Display:
A03 DVD
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : Pre OUT(ZONE2 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
only AV3311/991
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [9/WXYZ]
e
KEY9/WXYZ (Main Zone)
Initialization & Amp assign ZONE2 & Input
Mode Fixed DIGITAL
8.Press [ZONE SELECT], Select "ZONE2"
9.Press [ZONE ON]
r
ZONE2 POWER ON
10.Press [ZONE SELECT], Select "MAIN"
11.Press [DVD]
t
DVD (Main Zone)
4
DIGITAL (signal) Path
(ZONE3)
Input Mode : Fixed DIGITAL
Amp assign : ZONE3
ZONE3 Function : Source
Display:
A04 DVD
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : Digital / Output : Speakers (SURR BACK L/R)
·Input : Digital / Output : Pre OUT(ZONE3 L/R)
(
※
As the input source, you can switch from DVD to other ones.)
only AVR3311
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [0/_*]
e
KEY 0/CODE2 (Main Zone)
Initialization & Amp assign ZONE3 & Input
Mode Fixed DIGITAL
8.Press [ZONE SELECT], Select "ZONE3"
9.Press [ZONE ON]
r
ZONE3 POWER ON
10.Press [ZONE SELECT], Select "MAIN"
11.Press [DVD]
t
DVD (Main Zone)
5
HDMI (signal) Path Input Mode : Fixed HDMI
Amp assign : NORMAL
Display:
A05 DVD
1.Press [AMP]
2.Press [ZONE SELECT] , Select "ZONE2"
3.Press [ZONE OFF]
q
ZONE2 POWER OFF ·Input : HDMI / Output : Speakers (Front L/R)
·Input : HDMI / Output : Pre OUT(Front L/R)
(
※
As the input source, you can switch from DVD to other ones.)
4.Press [ZONE SELECT], Select "ZONE3"
5.Press [ZONE OFF]
w
ZONE3 POWER OFF
6.Press [ZONE SELECT], Select "MAIN"
7.Press [MULTEQ]
e
MULTEQ Select
Initialization &Amp assign NORMAL & Input
Mode Fixed HDMI
8.Press [DVD]
r
DVD (Main Zone)
23
fi g.10
fi g.11
fi g.12
fi g.13
fi g.14
