72
DDC_CLK/DDC_DATA/TMDS : Check item (15),(17),(25)
INPUTDE/INPUTVSN/INPUTHSN/INPUTVCLK : Check item (21)
0.9V
2.48V
DDC_CLK
DDC_DATA
16.68ms
INPUTHSN
INPUTVSN
INPUTHSN
INPUTVSN
31.84us
31.76us
INPUTDE
INPUTDE
IPINPCK
37.0ns
