2 No video is shown on the TV
Symptom Cause/Solution Page
No picture appears. •Check the connections for all devices.
•Insert connection cables all the way in.
•Check that input connectors and output connectors are not reversely connected.
•Check cables for damage.
•Match the input settings to the input connector of the TV connected to this unit.
•Check that the proper input source is selected.
•Check the video input connector setting.
•Check that the resolution of the player corresponds to that of the TV.
•Check whether the TV is compatible with copyright protection (HDCP). If connected to a
device not compatible with HDCP, video will not be output correctly.
31,32,34,35,
36,37,39,41
–
–
–
149
46, 122
149
176
200
No video is shown on the TV with the
DVI-D connection.
•With the DVI-D connection, on some device combinations, devices may not function properly
due to the copy guard copyright protection (HDCP).
200
No video from an input source such
as a game console is shown on the
TV.
•When special video signals are input from a game console, etc., the video conversion function
may not function. Connect the input connector to the monitor output connector of the same
type.
–
While the menu is being displayed, no
video is shown on the TV.
•When the menu is operated during playback of some 3D video contents or of video at some
computer resolutions (such as VGA), no playback video is shown in the background of the
menu.
–
When using HDMI ZONE2, the video
output in MAIN ZONE is interrupted.
•When ZONE2 is operated with the same input source selected for MAIN ZONE and ZONE2,
video in MAIN ZONE may be interrupted.
–

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
