Denon AVR-X3000 User Manual

196
Appendix
SettingsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Tips
2 The HDMI control function does not work
Symptom Cause/Solution Page
The HDMI control function does not
work.
•Check that “HDMI Control” in the menu is set to “On”.
•You cannot operate devices that are not compatible with the HDMI control function. In
addition, depending on the connected device or the settings, the HDMI control function may
not work. In this case, operate the external device directly.
•Check that the HDMI control function setting is enabled on all devices connected to this unit.
•When you make connection related changes such as connecting an additional HDMI device,
the link operation settings may be initialized. Turn o this unit and devices connected via
HDMI, and turn them on again.
145
113
113
113
2 When using HDMI ZONE2, the devices does not function properly
Symptom Cause/Solution Page
When using MAIN ZONE, video
output is interrupted in HDMI ZONE2.
•With the same input source selected for MAIN ZONE and ZONE2, when you operate MAIN
ZONE, video may be interrupted in HDMI ZONE2.
–
When using HDMI ZONE2, no video
or audio is output from the TV in
ZONE2.
•Check that the power is on for ZONE2.
•Check the input source for ZONE2.
•The AUX-HDMI connector on the front panel does not support the HDMI ZONE2 function.
•In ZONE2, playback is only possible when the input signals are HDMI signals.
•When the TV does not support the input audio format, audio is not output. Set the audio
format to “PCM” on the playback device. Alternatively, set “ZONE2 Setup” – “HDMI Audio”
in the menu to “PCM”.
•When the TV is not compatible with the resolution of the input video, no video is output. Set
the output resolution on the playback device to a resolution that is compatible with the TV.
122
122
–
–
173
–
When using HDMI ZONE2, MAIN
ZONE audio is played back as PCM.
•When the same input source is selected for MAIN ZONE and ZONE2, the audio format is
limited according to the specifications of the TV in ZONE2.
–

Denon AVR-X3000 Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	102 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	135 W
Power output per channel (20-20KHz@8 Ohm)	105 W
HDMI in	7
Audio (L/R) in	5
Composite video in	3
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	Banana connector
Audio formats supported	AAC, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Wi-Fi	No
RDS features	PTY, TP
AM band range	520 - 1710 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Supported video modes	1080i, 1080p, 480p, 576p, 720p
Display	VFL
Color depth	24 bit
Aspect ratio	4:3, 16:9
Product color	Black
Audio decoders	DTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Cables included	AC

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	10700 g
