60
Appendix
TipsSettingsConnections
Contents
Front panel Display Rear panel IndexRemote
Playback
Tuning in to radio stations and
presetting them automatically
(Auto Preset Memory)
Up to 56 stations can be preset.
If “Auto Preset Memory” is performed after performing “Preset Memory”,
the “Preset Memory” settings will be overwritten.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Auto Preset Memory”, then press
ENTER.
3
Press ENTER.
The unit starts to tune in to radio stations automatically and preset
them.
•When presetting is completed, “Completed” is displayed for
about 5 seconds and the option menu screen turns o.
Specify a name for the preset broadcast
station (Preset Name)
You can set the name to the preset broadcast station or change it.
Up to eight characters can be input.
1
Press OPTION.
The option menu screen is displayed.
2
Use ui to select “Preset Name”, then press ENTER.
The Preset Name screen is displayed.
3
Use o p to select the group of the broadcast station you
want to name.
4
Use ui to select the broadcast station you want to
name, then press ENTER.
5
Use ui to select a name label, then press ENTER.
The screen that lets you edit the preset name is displayed.
•If you select “Set Defaults”, then the unit returns to displaying
the frequency.
6
Enter the characters, then press “OK”.
•For character input, see page132.

Table of Contents

Other manuals for Denon AVR-X3000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X3000 and is the answer not in the manual?

Denon AVR-X3000 Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 100000 Hz
Output impedance16 Ω
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels7.1 channels
Signal-to-Noise Ratio (SNR)102 dB
Total Harmonic Distortion (THD)0.08 %
Power output per channel (1KHz@6 Ohm)135 W
Power output per channel (20-20KHz@8 Ohm)105 W
HDMI in7
Audio (L/R) in5
Composite video in3
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Connectivity technologyWired
Speakers connectivity typeBanana connector
Audio formats supportedAAC, FLAC, MP3, WAV, WMA
Image formats supportedJPG
Wi-FiNo
RDS featuresPTY, TP
AM band range520 - 1710 kHz
FM band range87.5 - 108 MHz
Supported radio bandsAM, FM
Internet radio services supportedSpotify, vTuner
Supported video modes1080i, 1080p, 480p, 576p, 720p
DisplayVFL
Color depth24 bit
Aspect ratio4:3, 16:9
Product colorBlack
Audio decodersDTS Neo:X, Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, Dolby TrueHD, DTS, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD, DTS-HD Master Audio
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibilityiPhone, iPod
AC input voltage230 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)600 W
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth379 mm
Width434 mm
Height167 mm
Weight10700 g
