Denon AVR-X3300W Service Manual

Paths to be conrmed Display Settings What to conrm
4 HDMI
g.04a
g.04b
A05:HDMI
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : Surround Back
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ Speaker output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
5
Analog AD
(MAIN)
g.05a
g.05b
A06:AD
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Vol 60dB
Amp assign : Surround Back
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
・ Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・ Analog input ⇒ Speaker output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
6
Analog Amp Assign
(Amp Assign :
ZONE2)
g.06
A07:ASSIGN-Z2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Vol 60dB
Amp assign : ZONE2
MAIN ZONE : On
ZONE2 : On
・ Analog input ⇒ Speaker output (Surround Back (ZONE2) L/R)
・ Analog input ⇒ Pre OUT output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
7
Amp Assign
(Amp Assign :
BiAMP)
g.07a
g.07b
A11:ASSIGN-BiAMP
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : Bi-Amp
MAIN ZONE : ON
ZONE2 : OFF
・ Analog input ⇒ Speaker output (Surround Back L/R → Front L/R)
・ Conrmation of Pre OUT No.
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
8 Front Height
g.08a
g.08b
A14:FRONT HEIGHT
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : Front Height
MAIN ZONE : ON
ZONE2 : OFF
・ Analog input ⇒ Speaker output Surround Back L/R (Front Height output)
・ Analog input ⇒ Speaker output Surround Back L/R (Front Height output)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume 60 is the value when Absolute settings are used. The value is -20 when Relative set-
tings are used)
1.6. Conrmation items for the video system
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1 Analog Video pass g.09
V01:VIDEO PASS
Input Source : CBL/SAT
MAIN ZONE : On
ZONE2 : On
・ Component input ⇒ Component output (X3300E3 ONLY)
(
b
The input source can be switched to any source except CBL/SAT.)
2
Video Convert
(HDMI ⇒ HDMI)
(Analog ⇒ HDMI)
g.10
V02:V.CONVERT
Input Source : CBL/SAT
Video Conversion (IP Scaler) : "Auto", All sources
IP Scaler : "HDMI", All sources
Resolution : "Auto", All sources
MAIN ZONE : On
ZONE2 : Off
・ HDMI input ⇒ IP Scaler ⇒ HDMI output.
・ ETHERNET input ⇒ IP Scaler ⇒ HDMI output.
・ CVBS input ⇒ IP Scaler ⇒ HDMI Output
・ Component input ⇒ IP Scaler ⇒ HDMI Output
(
b
The input source can be switched to any source except CBL/SAT.)
128
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
