Denon AVR-X3300W Service Manual

Paths to be conrmed Display Settings What to conrm
3
HDMI pass
(MAIN ZONE)
g.11
V03:HDMI PASS
Input Source : CBL/SAT
Video Conversion (IP Scaler) : Off
MAIN ZONE : On
ZONE2 : Off
・ HDMI input (MAIN function) ⇒ HDMI output (MAIN)
(
b
The input source can be switched to any source except CBL/SAT.)
4
HDMI CEC
(Control Monitor :
HDMI Monitor1)
g.12
V04:HDMI CEC
Input Source : CBL/SAT
HDMI Control : On
Control Monitor : Monitor1 (if checking the HDMI
Monitor Out1)
MAIN ZONE : On
ZONE2 : Off
・ When the power supply of a TV is put in the standby mode, make sure that the power supply
of this unit is also put in the standby mode.
(
b
The input source can be switched to any source except CBL/SAT.)
・ The ARC path can also be checked (check this using the TV input source).
5
HDMI Audio
(Audio : AVR)
g.13a
g.13b
V05:H.AUDIO-AVR
Input Source : CBL/SAT
HDMI Control : Off
HDMI Audio : AVR (if checking the audio output from
AVR)
・ HDMI input (PCM , DolbyDigital , DTS) ⇒ Speaker output.
・ HDMI input(HD audio) ⇒ Speaker output.
(
b
The input source can be switched to any source except CBL/SAT.)
6
HDMI Audio
(Audio : TV)
g.14
V06:H.AUDIO-TV
HDMI Audio : TV (if checking the audio output from TV)・ HDMI input (PCM , DolbyDigital , DTS) ⇒ HDMI output (audio output from connected TV)
(
b
The input source can be switched to any source except CBL/SAT.)
7 GUI g.15
V07:GUI MENU ON
Input Source : CBL/SAT
IP Scaler : On, All sources
Resolution : "AUTO", All sources
Setup Menu : On
MAIN ZONE : On
ZONE2 : Off
・ GUI display ⇒ HDMI output.
(
b
The input source can be switched to any source except CBL/SAT.)
8
HDMI pass
(ZONE2)
g.16
V08:ZONE2 HDMI
Input Source : CBL/SAT
Z2 Source : Source
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
・ HDMI input (ZONE2 Function) ⇒ HDMI output (ZONE2)
(
b
The input source can be switched to any source except CBL/SAT.)
129
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
