Denon AVR-X3300W Service Manual

Check the USB device being used
YES
Is the USB device supported by this unit?
Is a USB hub being used?
This unit supports devices in the FAT16- and
FAT32-formatted mass storage class, MTP-
compatible devices and iPod devices (except for
some models).
Do not use a USB hub.
NO
Checking the unit
YES
YES
Can a voltage (5V) be conrmed between pin
1 and pin 4 of CP4406 (USB Connector) on USB
PCB?
The USB signal circuit between CY920 and CP4406 of the USB PCB are faulty.
Are N1008 of the HDMI PCB and CN4402 of the
USB PCB correctly connected?
The circuit around U1006 of the HDMI PCB is
faulty.
Connect the connectors correctly.
5.3. Cannot recognize the connected USB device
YES
NO
NO
NO
Checking the unit (If no picture is output)
YES
• Check the VIDEO circuit.
Are digital video signals(920PCK, 920VD0 -
920VD7) output from CY920 to U1011 (V.PLD)?
Checking the unit:(If no sound is output)
YES
YES
Check the U1073(DSP) AUDIO circuit and the circuits thereafter.
Are the I2S signal output to pins 26, 28, 30 and
34 of the U1008 HDMI PCB ?
(The 30, 32, 34pin in the case of DSD)
Are audio signal output to pin 64 of U1041
(A.PLD) on HDMI PCB.
5.4. No picture or sound is output
The circuit around CY920, U1011 (V.PLD) is
faulty.
The CY920 is faulty.
The circuit around U1041(A.PLD) is faulty.
NO
NO
NO
79
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X3300W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	7.2
Pre-out connectivity	Yes
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.05 %
Power output per channel (1KHz@6 Ohm)	180 W
Power output per channel (20-20KHz@8 Ohm)	105 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	600 W
Product color	Black
Audio decoders	DTS-HD, DTS-HD Master Audio, Dolby TrueHD
Multi-Zone quantity	2
Apple docking compatibility	-
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
HDMI in	8
Audio (L/R) in	5
Remote control in	1
Composite video in	3
Composite video out	0
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Audio formats supported	AAC, AIFF, ALAC, DSD, FLAC, MP3, WAV, WMA

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	10800 g
