1.4. Error display
See the table below for descriptions of the displayed errors and countermeasures for these.
If multiple errors occur, only one item is displayed.
The priority order is
w
,
e
,
r
,
t
,
y
,
q
.
Condition States Display TROUBLE SHOOTING
q
Firm Check
NG
(
#
: 1/2/3/4)
The model name, brand name and region information
written in the rmware are compared to the region
settings in the PCB. This error is displayed if the infor-
mation does not match.
" ▲ " is displayed as the rst character if the rmware
is not correct (see the illustrations on the right).
FIRM ERROR
–
Main :**:**
–
Main FBL :**.**
–
DSP# :**.**
–
Audio PLD:**.**
–
Video PLD:**.**
–
GUI :********
• Check the resistor for setting the
region(R1590 / R1589, DIGITAL PCB).
• Write the rmware for the correct
region.
w
IP SCALER NG
An error occurs in Loop back Test of the DDR memory
which is performed during the initial setting of i/p
Scaler(ADV8003).
IP SCALER ERR 01
• Check the circuits around the IP
SCALER (IC401, DIGITAL PCB) and
DDR2 (IC402/IC403).
If there appear to be no problems,
IC401 or IC402/IC403 is faulty.
During the initial setting of i/p Scaler ( ADV8003 ) ,
there is not the reply of the Loop back Test result of
the DDR memory .
IP SCALER ERR 02
e
GUI Serial
Flash NG
If the Main CPU version is not supported by the GUI
Serial Flash (ADV8003).
" ▼ " is displayed as the rst character of the GUI
rmware version.
GUI VER. ERROR
•
GUI :********
• Check the rmware version.
r
DIR NG
This error is displayed if there is no response from the
DIR.
DIR ERROR 01
• Check the DIR (IC202, DIGITAL PCB)
and surrounding circuits.
t
DSP NG
(
#
: 1/2/3/4)
The DSP FLAG0 port does not enter "
Hi
" status while
booting a DSP code even after resetting DSP.
DSP# ERROR 01
• Check the DSP (IC251/IC261/IC271/
IC281, DIGITAL PCB) and surrounding
circuits.
The DSP FLAG0 port does not enter "
Hi
" status before
issuing a DSP command.
DSP# ERROR 02
Setting WRITE to "
Lo
" does not set ACK to "
Hi
" during
DSP data reading.
DSP# ERROR 03
Setting REQ to "
Lo
" does not set ACK to "
Lo
" during
DSP data reading.
DSP# ERROR 04
Setting WRITE to "
Hi
" does not set ACK to "
Hi
" during
DSP data writing.
DSP# ERROR 05
Setting REQ to "
Lo
" does not set ACK to "
Lo
" during
DSP data writing.
DSP# ERROR 06
y
EEPROM NG
An error occurred in a checksum of the EEPROM(*** is
a block address number).
BACKUP ERROR
131
