Denon AVR-X4300H Service Manual

DIAGNOSTIC MODE
Service Path Check Mode
1.1. Actions
This function is convenient for conrming problem paths in the product and checking the paths after repairing.
The Video and Audio paths can be checked.
The backup data is not rewritten.
1.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button to turn on the power.
Select the "
1. SERVICE CHECK
" using the "
TUNER PRESET CH+
" button, then press the "
STATUS
" button then to conrm.
The "
TUNED
", "
STEREO
" and "
RDS
" segments are lit in this mode.
1.3. Canceling diagnostic mode
Press the power button to turn off the power.
1.4. Selecting items to check
Press the
q
button to switch between video items and audio items.
Press the
w
or
e
button to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER CURSOR
0
CURSOR
1
SLEEP CURSOR
0
CURSOR
1
1.5. Audio system conrmation items
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1 Analog g.01
A01:ANALOG PASS
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : DIRECT
Amp assign : 9.1ch
Floor Layout : 5.1&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Analog input ⇒ Speaker output (Front L/R)
・ Analog input ⇒ Pre OUT output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
2
DIGITAL
(MAIN)
g.02a
g.02b
A02:DIGITAL
Input Source : CBL/SAT
Input Mode : DIGITAL (xed)
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5.1&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small / SW = Yes(2ch)
MAIN ZONE : On
ZONE2 : Off
ZONE3 : Off
・ Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, S.Back L/R)
・ Digital input ⇒ Pre output (Front L/R, Center, Surround L/R, S.Back L/R, Subwoofer1/2)
(
b
The input source can be switched to any source except CBL/SAT.)
142
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
