Denon AVR-X4300H Service Manual

DIGITAL
DIGITAL PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1101 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1102 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1501 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1901 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1902 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1903 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D1904 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
IC111 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC112 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC113 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC117 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC118 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC119 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC120 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC121 943239101860S I.C , DC-DC CONVERTER(SOT-23)
CVITPS563200DDCR
1
IC123 943239010400S I.C, REGULATOR(3.3V/TO-252) CVINJM2845DL133 1
IC151 943243103410S
I.C , MAIN CPU(AVR-X4300HBKE3)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2339AV 1 *
IC171 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC172 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC173 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC174 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC175 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC176 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC177 943233102030S I.C , Shift/Store Register(SOIC-16P)
CVIMC74HC4094ADR2G
1
IC201 00D2623077900 I.C, HEX INVERTER
HVITC74VHCU04FT 1
IC202 23681014050AS I.C , DIR/DIT(WITH ADC,LQFP-48P) CVIPCM9211PTR 1
IC203 943236101520D I.C , DIR(SSOP-16) CVILC89091JA-H 1
IC204 943236101520D I.C , DIR(SSOP-16) CVILC89091JA-H 1
IC221 943239101920S
I.C , APLD(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2365AV 1 *
IC223 236810083506S I.C , CLOCK JITTER
CVICS210010-CZZR
1
IC251 943245100910S I.C , DSP(LQFP-176P/400M)
CVIADSP214874B28-1
1*
IC252 24681008960AS I.C , SDRAM(256M,TSOP-54P)
CVIA3V56S40GTP-60
1
IC254 943248103910S
I.C , DSP1_S.FLASH(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2349AV 1 *
IC261 943245100910S I.C , DSP(LQFP-176P/400M)
CVIADSP214874B28-2
1*
IC262 24681008960AS I.C , SDRAM(256M,TSOP-54P)
CVIA3V56S40GTP-60
1
IC264 943248103920S
I.C , DSP2_S.FLASH(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2350AV 1 *
IC271 943245100910S I.C , DSP(LQFP-176P/400M)
CVIADSP214874B28-3
1*
IC272 24681008960AS I.C , SDRAM(256M,TSOP-54P)
CVIA3V56S40GTP-60
1
IC273 943248103930S
I.C , DSP3_S.FLASH(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2351AV 1 *
IC281 943245100910S I.C , DSP(LQFP-176P/400M)
CVIADSP214874B28-4
1*
IC282 24681008960AS I.C , SDRAM(256M,TSOP-54P)
CVIA3V56S40GTP-60
1
IC283 943248103950S
I.C , DSP4_S.FLASH(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2352AV 1 *
IC306 236810086505S I.C , ADC(96kHz 24-Bit) CVIAK5358BET 1
IC321 23681012050AS I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC322 23681012050AS I.C , 2CH DAC(32BIT,384KHZ,TSSOP-20P) CVIPCM5100PWR 1
IC323 943231102150S IC, regulator(3.3V , SSOP5) CVIBU33TD3WG 1
IC351 23681012760AS I.C , HDMI RX
CVIADV7850KBCZ-5
1
IC381 23681050460AS I.C , HDMI 2.0 Transceiver (HQFP-144P) CVIMN864788 1
IC391 23681050460AS I.C , HDMI 2.0 Transceiver (HQFP-144P) CVIMN864788 1
IC392 943239101510S I.C , MUX/DEMUX (TSSOP-16P)
CVISN74CBT3251PWR
1
IC401 23681016160AS I.C , VSP(ADV8003KBCZ-8B) CVIAD55/058Z-0 1
IC402 24681020560AS I.C , DDR2 SDRAM(512Mbits, 84-FBGA)
CVIA3R12E40DBF-8E
1
IC403 24681020560AS I.C , DDR2 SDRAM(512Mbits, 84-FBGA)
CVIA3R12E40DBF-8E
1
IC404 943248103940S
I.C , OSD FLASH(AVR-X4300HBKE3)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2373AV 1 *
IC421 943239101930S
I.C , VPLD(AVR-X4300HBKE3/BKE2/SPE2/K)
See PROCEDURE AFTER REPLACING THE U-COM, ETC.
VVIANAM2369AV 1 *
IC431 23681050360AS I.C , HDMI 2.0 TX+SCALER CVIMN864787 1
IC502 23671011050AS I.C , IPOD AUTHENTICATION FROM D&M
CVI23671011050AS_DM
1
IC503 943239101090S I.C , High side switch (TSSOP-B8) CVIBD82065FVJ-E2 1
IC511 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
IC512 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
IC513 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
IC514 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
IC515 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
IC516 943239101940S I.C,LOW VOLTAGE MULTIPLEXER/DEMULTIPLEXER,TSSOP16
CVISN74CBTLV3257PWR
1*
Q1001 943239101550S FET, SSM6N15AFU, N-CH, SC-88, TOSHIBA CVTSSM6N15AFU 1
Q1101 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1102 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1103 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1104 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1105 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1106 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1107 00D2757001907 MOSFET (P-CH, 2.5V POWER TRENCH) CVTFDC608PZ 1
Q1111 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1112 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1113 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1114 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1115 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1116 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1117 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C 1
Q1118 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1
Q1119 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1
Q1121 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q1122 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1123 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q1124 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1125 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q1126 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1127 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q1128 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1131 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1133 00D2710326904 T.R,2SA1954 CVT2SA1954 1
Q1134 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1151 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q1152 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1
Q1501 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1502 943214500020S T.R,2SC3052 CVT2SC3052 1
Q1503 943214500030S EOL item T.R , MUTE CVTINC2001AC1 1
4

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
