Denon AVR-X4300H Service Manual

SPK
SPK PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D9221 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9222 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9223 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9224 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9225 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9226 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9228 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9229 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9230 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9231 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9233 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9234 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9241 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9242 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9243 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9244 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9245 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9246 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9247 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9248 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9249 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9250 943202501210S DIODE, ZENER(3.6V/0.5W, SOD-123) CVDMM1Z523V6B 1
D9303 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9304 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9315 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9316 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9317 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9318 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9331 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9333 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9336 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9338 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9339 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9340 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9342 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9343 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9345 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9348 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9350 943203003150S DIODE , RECTIFIER, RADIAL CVD1N4007SRT 1
D9355 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9356 nsp WIRE, COPPER(D0.6) C3A206 0.02
D9406 943202500750M DIODE , ZENER(8.2V/0.5W, SOD-123) CVDMM1Z8V2H 1
D9407 00D9430060501 DIODE , RECTIFIER HVD1SR159-200 1
D9416 943202500750M DIODE , ZENER(8.2V/0.5W, SOD-123) CVDMM1Z8V2H 1
D9417 00D9430060501 DIODE , RECTIFIER HVD1SR159-200 1
D9701 943206500030S DIODE , BRIDGE(600V/25A) CVDD25SB60 1
D9727 943202500840S DIODE , ZENER(7.5V/0.5W, SOD-123) CVDMM1Z7V5H 1
D9728 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9913 201310001503S DIODE, ULTRA-HIGH SPEED CVDKDS160RTKP 1
D9914 943202501210S DIODE, ZENER(3.6V/0.5W, SOD-123) CVDMM1Z523V6B 1
IC718 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC931 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC933 943232100370S I.C,REGULATOR(+12V,TO220) CVIKIA7812BPI 1
IC934 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI 1
IC935 00D2631099006 I.C,REGULATOR(-5V,T0220IS) CVIKIA7905PI 1
IC936 943231101930S I.C , REGULATOR(+7V,TO-220IS) CVIKIA7807BPI 1
IC937 943231101920S I.C , REGULATOR(-7V,TO-220IS) CVIKIA7907PI 1
Q9221 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9222 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9223 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9224 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9225 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9226 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9228 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9229 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9230 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9231 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9402 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q9403 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9404 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 1
Q9405 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9406 963219003340S T.R , BIAS CVTKTC3964 1
Q9412 943212500220D T.R, 2SA2166, PNP, TO-236, ISAHAYA CVT2SA2166 1
Q9413 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9414 943215500140D T.R,RT1P144C(10K-47K) CVTRT1P144C 1
Q9415 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C 1
Q9416 963219003340S T.R , BIAS CVTKTC3964 1
RESISTOR GROUP
R7801 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 1
R7802 nsp RES, M-OXIDE FILM(2W/470ohm) CRG2SANJ471RT 1
R9201 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9202 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9203 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9204 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9205 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9206 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9207 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9208 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9209 nsp RES, M-OXIDE FILM(1W/10ohm) CRG1SANJ100RT 1
R9211 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9212 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9213 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9214 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9215 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9216 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9217 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9218 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9219 nsp RES, M-OXIDE FILM(2W/10ohm) CRG2SANJ100RT 1
R9241 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9242 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9243 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9244 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9245 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9246 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
R9247 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1
31

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
