Denon AVR-X4300H Service Manual

VIDEO
REF No. Part No. Part Name Remarks Q'ty New Ver
C5187 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5188 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5189 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5190 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5191 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5192 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5193 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5211 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5212 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5213 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5215 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5221 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5222 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5223 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5225 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5226 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5231 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5233 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5234 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5235 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5236 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C5237 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5238 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1
C5239 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1
C5241 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5242 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5243 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5244 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5245 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5246 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5251 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C5252 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5253 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C5326 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5327 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5328 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5329 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5330 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5331 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C5332 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C5333 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
OTHER PARTS GROUP
BN21B nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) CJP19HJ282Z 1
BN27B nsp PINSOCKET(15P,1.25mm,ANGLE,B-TO-B) CJP15HJ282Z 1
BN28B nsp PINSOCKET(07P,1.25mm,ANGLE,B-TO-B) CJP07HJ282Z 1
JK511 943643102990S JACK, RCA 5P (Y/Y/Y/Y/Y) SILVER CJJ4T001Z 1
JK512 943643101910S JACK, 6P(G/G,B/B,R/R), SILVER CJJ4R054Z 1
JK513 943643101100S JACK, 3P(G/B/R), SILVER CJJ4S050Z 1
JK521 943646100420S JACK, 9P D-SUB FEMALE(RS-232C) CJJ9W001Z 1
JK522 643010086019S JACK, STEREO (RED MOLD) CJJ2D019Z 1
JK523 643010086019S JACK, STEREO (RED MOLD) CJJ2D019Z 1
JK525 90M-YT004860R JACK, STEREO (BLK MOLD) CJJ2D008Z 1
JK526 90M-YT004860R JACK, STEREO (BLK MOLD) CJJ2D008Z 1
L5164 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5165 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5166 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5311 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5312 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5313 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5314 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L5315 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
30

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
