Denon AVR-X4300H Service Manual

HDMI DIAGRAM
MAIN
SUB
SUB
MAIN
HDMI OUT2
HDMI ZONE2
P0 TX
HDMI IN1
HDMI IN2
HDMI IN3
HDMI IN4
HDMI IN5
HDMI IN6
(CBL/SAT)
(DVD)
(BLU-RAY)
(GAME)
(MEDIA Player)
(AUX2)
HDMI IN7
(CD)
HDMI IN8
(AUX1)
AD8195
BUFFER
HDMI OUT1
ARC
HDMI SW2(MN864788)
HDMI TX(MN864787)
DEC_Y_IN
DEC_PB_IN
DEC_PR_IN
DEC_CVBS_IN
VIDEO BLOCK_B1
VIDEO PLD
AD55/058Z-0(ADV8003-8B)
DDR2 SDRAM
512M
DDR2 SDRAM
512M
S. FLASH
128M
MX25L12835FMI-10G
A3R12E40CBF-8E A3R12E40CBF-8E
P3 RX
P2 RX
P1 RX
P0 RX
P0 TX
P1 TX
P3 RX
P2 RX
P1 RX
P0 RX
P0 TX
P1
TX
P1 RX
P0 RX
P3 RX
P2 RX
ADV7850
VIDEO SIGNAL OUT
VIDEO INPUT
DIGITAL AUDIO BLOCK_B6
ANALOG
HDMI Rx
P1 TX
Matrix SW
600MHz
Rxlink0 Txlink0
Txlink1
4K/2K
Up Scaler
HDMI Tx
Matrix SW
600MHz
600MHz
DDR2 INTERFACE
CONTROL
Video Processor(1080P, OSD, IP Conv,)
4K/2K
4K/2K
WITH TMDS
EPM570F256C4N
Z2HDMISPDIF
RXI2S0~3, RXSPDIF
HDMI SW1(MN864788)
TXDATA0
TXBCK, TXLRCK
TXDATA0
TXBCK, TXLRCK
RXMCK, RXBCK, RXLRCK, RXINT 0
RXMCK, RXBCK, RXLRCK, RXINT 0
B0~B 7/G0~G7/R0~R7
PCK/H
SYNC/VSYNC/DE
B0~B 7/G0~G7/R0~R7
PCK/HSYNC/VSYNC/DE
B0~B 7/G0~G7/R0~R7
PCK/HSYNC/VSYNC/DE
B0~B 7/G0~G7/R0~R7
PCK/HSYNC/VSYNC/DE
RXI2S0~3, RXSPDIF
Z2_HAINT
105 119
LEGO_PCK
LEGO_RGB Date(24bit)
LEGO_Date Enable
LEGO_Vsync
LEGO_Hsync
LEGO_PCK
LEGO_RGB Date(24bit)
LEGO_Date Enable
LEGO_Vsync
LEGO_Hsync
27.000MHz
27.000MHz
27.000MHz
27.000MHz
27.000MHz
AVRX4300H HDMI BLOCK
58
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
