5. Network / Bluetooth / USB
Check the setting
YES
YES
YES
YES
Are the network settings of this unit correct?
Are peripheral devices such as the router and
hub connected to this unit correctly?
Are the router settings correct?
Set the IP address, etc. correctly.
When the static IP address is used, check that no
other devices have the same IP address and that
the subnet mask settings are correct.
Connect the peripheral devices correctly.
Check the instruction manual of the router and
congure the settings correctly.
Check that there are no connection restrictions
by MAC addresses, etc.
5.1. Cannot connect to the network
Is the LAN cable correctly inserted?
Insert the LAN cable correctly and then turn on
the power again.
Check the connection environment
Checking the unit
YES
YES
YES
Can the output voltage (3.3V)
to IC112 (DC-DC Conv.) be
conrmed?
Can the voltage (5V) be conrmed between pin
2 and pin 5 of CN903?
Is D5V_POWER (IC151 uCOM
136 pin) "Hi" ?
The circuit of D5V_POWER
between IC151 and IC112 are
faulty.
The circuit around IC112 (DC-
DC.Conv.) is faulty.
The circuit between the AC inlet and CN903 is
faulty.
Check the SMPS PCB.
YES
YES
NO
NO
NO
NO
NO
NO
NO
NO
NO
Can the NET3.3V output volt-
age (3.3 V) to Q1102 (FET-SW)
be conrmed?
Is NET3.3V POWER (IC151
uCOM 135 pin) "Hi" ?
The circuit of NET3.3V POWER
between IC151 and Q1102
are faulty.
The circuit around Q1102
(FET-SW) is faulty.
Go to next page.
YES
YES
NO
NO
Can the output voltage (5 V)
to Q1101 (FET-SW) be con-
rmed?
Is NET5V POWER (IC151 uCOM
48 pin) "Hi" ?
NET5V POWER circuit is faulty
between IC115-Q1101 (FET-
SW).
The circuit around Q1101
(FET-SW) is faulty.
87
