Denon AVR-X4300H Service Manual

FRONT CNT
FRONT CNT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC301 943239101840S I.C , 8CH Premium DAC(QFN-48P) CVIAK4458VN 1
IC302 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC303 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC304 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC305 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC311 943239101840S I.C , 8CH Premium DAC(QFN-48P) CVIAK4458VN 1
IC312 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC313 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC314 943232100380S I.C , DUAL OPAMP(SOP-8P) CVINJM8080G 1
IC315 00MHC10172090 I.C , OP AMP HVINJM2115MTE1 1
IC316 00MHC10172090 I.C , OP AMP HVINJM2115MTE1 1
RESISTOR GROUP
R3001 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R3002 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3011 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3012 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3013 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3014 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3015 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3016 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3017 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3018 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3019 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3020 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3021 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3022 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3023 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3024 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3025 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3026 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3027 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3028 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3029 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3030 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3031 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3032 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3033 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3034 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3035 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3036 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3037 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R3038 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3039 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R3040 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3041 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3042 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3043 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3044 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3045 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3046 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3047 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3049 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3051 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3053 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3055 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R3057 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R3059 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R3061 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R3063 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3065 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3066 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3067 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3068 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3069 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3071 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3073 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3074 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3075 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3076 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3077 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3078 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3079 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3080 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3081 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3083 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3085 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3086 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3102 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R3111 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3112 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3113 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3114 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3115 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3116 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3117 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3118 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3119 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3120 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3121 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3122 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3123 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3124 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3125 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3126 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3127 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3128 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3129 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3130 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3131 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3132 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3133 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3134 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3135 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3136 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3137 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
34

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
