Denon AVR-X4300H Service Manual

FRONT CNT
REF No. Part No. Part Name Remarks Q'ty New Ver
R3138 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3139 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3140 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3141 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3142 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3143 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3144 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3145 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3147 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3149 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3150 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3151 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3152 nsp RES, CHIP(1608/5%/3.9Kohm) CRJ10DJ392T 1
R3153 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3154 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3155 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3156 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3157 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3158 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3159 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3160 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R3161 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3162 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R3163 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3164 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3165 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3166 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3171 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3172 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3173 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R3174 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3175 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3176 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R3177 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3178 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3179 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3180 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3181 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R3182 nsp RES, CHIP(1608/5%/12Kohm) CRJ10DJ123T 1
R3183 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1
R3184 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1
R3185 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3186 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R3307 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1
R9801 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9802 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9803 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9804 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9806 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R9819 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R9820 nsp RES, CHIP(1608/5%/27Kohm) CRJ10DJ273T 1
R9821 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9822 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1
R9823 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
R9824 nsp RES, CHIP(1608/5%/270ohm) CRJ10DJ271T 1
CAPACIITORS GROUP
C3003 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3004 nsp CAP, ELECT(100V/1uF),85'C Black CCEA2AH1R0T 1
C3012 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3013 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3015 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3016 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3017 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3018 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3021 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3022 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3023 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3024 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3025 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3026 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3027 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3028 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3031 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3032 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3033 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3037 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3038 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3039 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3040 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3041 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3042 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3055 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3056 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3057 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3058 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3061 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3062 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3063 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3064 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3065 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3066 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3067 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3068 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3069 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3103 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3121 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3122 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3123 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3124 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3125 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3126 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3129 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3130 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3131 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3132 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3133 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3134 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3135 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3136 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3139 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3140 nsp CAP, CHIP(2012, 50V/3900pF, MURATA GRM21)
CCUMUC1H392JAM
1
C3141 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3142 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
35

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
