PACKING
PACKING
※Parts indicated b
"ns
"on this table cannot be su
lied. Part indicated b
"
" mark is not illustrated in the ex
loded vie
※The
arts listed below are onl
for maintenance. Therefore the
mi
ht differ from the
arts used in the unit in a
earances or dimension
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
1 - SET , AV RECEIVER -1
2 nsp POLY SHEET VPB1A213 1
3 - TAPE , P.P(24MM*50MM) C4F3247YE 0.5
4 943533103520S PAD , SNOW BOTTOM VPS1A1076 1 *
5 943533103510S PAD , SNOW TOP VPS1A1075 1 *
6 943531105960S BOX , OUT CARTON E3 VPG1A1103Z 1 *
6 943531105980S BOX , OUT CARTON E2 VPG1A1103Y 1 *
6 943531105970S BOX , OUT CARTON JP VPG1A1103X 1 *
7 nsp TAPE , OPP(50) V4FC500CL 2
8 - INSTRUCTION MANUAL ASS'Y - 1 *
@8-1 nsp BAG , ZIPPER POLY(A5) VPB1A227Z 1
@8-1-1 nsp LABEL , BAR CODE(MANUAL) VQB1A971 1
@8-2 nsp SHEET , SPOTIFY INSERTION E3, E2 VQE1A880Z 1 *
@8-3 nsp HEOS INSERTION E3, JP CQE1A887Z 1 *
@8-3 nsp HEOS INSERTION E2 CQE1A888Z 1 *
@8-4 35201045400AD CD MANUAL ASS'Y JP VFT1A192ZA 1 *
@8-5 54111138700AD MANUAL , GUIDE E3 VQX1A1985Z 1 *
@8-5 54111138400AD MANUAL , GUIDE E2 VQX1A1986Z 1 *
@8-5 54111138300AD MANUAL , GUIDE JP VQX1A1987Z 1 *
9 - ACCESSORY ASS'Y -1*
@9-1 nsp BAG,POLY VPB1A216Z 1
@9-1-1 nsp LABEL , BAR CODE(MANUAL) VQB1A971 1
@9-2 963116100070S ANT, AM LOOP(9.5uH/5T) CSA1A039Y 1
@9-2-1 nsp LABEL , AM ANTENNA VQB1A1240Z 1
@9-3 943116100170D FM 1 POLE ANT ( UL TYPE ) CSA1A044Z 1
@9-3-1 nsp LABEL , FM ANTENNA VQB1A1241Z 1
@9-4 nsp CARD , WARRANTY E3 VQE1A224N 1
@9-5 nsp SHEET , INSERTION E3 CQE1A559Z 1
@9-6 943544104890S LABEL , SPEAKER CABLE CQB1A1514Z 1
@9-7 nsp SAFETY INSTRUCTION E3 VQE1A889Z 1 *
@9-7 nsp SAFETY INSTRUCTION E2 VQE1A890Z 1 *
@9-7 nsp SAFETY INSTRUCTION JP VQE1A891Z 1 *
@9-8 nsp SHEET , USING BATTERIES E2 VQE1A867Z 1 *
@9-9 nsp NOTE ON RADIO E3 VQE1A892Z 1 *
@9-9 nsp NOTE ON RADIO E2 VQE1A893Z 1 *
@9-9 nsp NOTE ON RADIO JP VQE1A894Z 1 *
10 nsp WIFI-FLY SHEET ASS'Y VQE1A728WA 1 *
@10-1 nsp POLY , BAG VPB1A240Z 1
@10-2 nsp SHEET , WIFI ANTENNA FLY VQB1A971 1 *
@10-3_EXPLODED-A
- ROD ANTENNA -2*
11 42911002000AS MIC STAND ASS'Y CPG1A1021YA 1
! 12 943611501140S CORD , POWER (13A/125V,USA,INLET) E3 VJA2A070ZV01 1
! 12 943611501150S CORD , POWER (10A/250V,EUR,INLET) E2 VJA2B054ZV01 1
! 12 943611501130S CORD , POWER (12A/125V,JPN,INLET) JP CJA2J121X01 1
13 nsp BAG , POLY VPB1A008Z 1
13-1 nsp LABEL , SERIAL NO VQB1A995 1
14 30701022600AS REMOCON ASS'Y, (RC-1211) CARTAVRX4300H 1 *
15 nsp BATTERY , AA 2PCS IN PACK CABR6PPB-GN 2
16 32401000800AD MIC , AUDYSSEY CJXACM1HB 1
17 nsp LABEL , MIC VQB1A1242Z 1
18 nsp LABEL , CONTROL VQB2A993Z 1
18-1 - └ LABEL , SERIAL NO -*
18-2 - └ LABEL , FCC ID E3 - *
18-2 - └ LABEL , PRODUCTION DATE JP - *
19 544110091014M LABEL , WHITE M1 SG SP VQB1A908Z 2
20 nsp LABEL , DO NOT RETURN E3 CQB1A1516Z 1 *
21 nsp LABEL , HEOS BOX E3 CQB1A1531Z 2 *
22 nsp CARD , GUARANTEE (M) JP VQE1A194S 1
23 nsp LABEL , POP E3 CQB1A1501Y 1 *
24 nsp LABEL , POP E2 CQB1A1502Z 1 *
24 nsp LABEL , POP JP CQB1A1503Z 1 *
25 nsp LABEL , SPOTIFY(BK) BKE3, BKE2 CQB1A1458Z 1
25 nsp LABEL , SPOTIFY(SP) SPE2 CQB1A1459Z 1
26 nsp TAPE , FILAMENT V4FE187 0.15 *
27 nsp LABEL , HEOS PANEL E3 CQB1A1513Z 1 *
28 nsp LABEL , LICENSE CQB1A1520Z 1
29 nsp ORNAMENT , REAR PANEL CGX1A526Z 1 *
