Denon AVR-X4300H Service Manual

EXPLODED
REF No. Part No. Part Name Remarks Q'ty New Ver
M25 nsp NUT - ENCORDER -2*
M26 nsp WASHER - ENCORDER -2*
P1 943416100770D WINDOW , VFD CGU1A463Z 1
P2 943451101230D SHEET , VOLUME KNOB CGX1A473 1
P3 943451101210D SHEET , SELECT KNOB CGX1A474 1
P4 42451003000AD RING , SELECT BK CGR1A536 1
P4 42451003001AD RING , SELECT SP CGR1A536C73 1
P5 42451002900AD RING , VOLUME BK CGR1A535 1
P5 42451002901AD RING , VOLUME SP CGR1A535C73 1
P6 943415100350D HOLDER , DOOR BK CKG1A056 1
P6 943415100360D HOLDER , DOOR SP CKG1A056G45 1
P7 943422101070S SHEET , ORNAMENT E3, JP CGX1A470S 1
P7 943422101080S SHEET , ORNAMENT BKE2 CGX1A470R 1
P7 943422101090S SHEET , ORNAMENT SPE2 CGX1A470Q 1
P8 943413100390D CAP , DOOR CHG1A551 1
P9 00M446T056010 CUSHION,DOOR CHG1A296Y 2
P10 943443101160S PANEL , INNER BK VGW3A521 1 *
P10 943443101150S PANEL , INNER SP VGW3A521G45 1 *
P11 943423100510D INDICATOR , POWER CGL1A299A36 1
P12 943411101750D BUTTON , POWER BK CBT1A1167 1
P12 943411101760D BUTTON , POWER SP CBT1A1167C73 1
P13 nsp COVER , DOOR A CMH1A329 1
P14 nsp GEAR , DAMPER SR6003 CDG1A027W 1
P15 943411103310D BUTTON , ENTER E3, JP CBT1A1165X 1
P15 943411103320D BUTTON , ENTER BKE2 CBT1A1165Z 1
P15 943411103330D BUTTON , ENTER SPE2 CBT1A1165YG45 1
P16 nsp COVER , DOOR B CMH1A330 1
P17 963407100420D FOOT CKL1A225 4
P18 00D9630214607 CUSHION FOOT VHG2A289 4
P19 nsp RUBBER VHG1A113 5
P20 nsp CUSHION SUPPORT VHG1A305 2
P21 nsp SNAP RIVET CRE1A136 1
P22 nsp SUPPORT, PCB CRE1A102 1
P23_Packing23 nsp LABEL , POP E3 CQB1A1501Y 1 *
P23_Packing24 nsp LABEL , POP E2 CQB1A1502Z 1 *
P23_Packing24 nsp LABEL , POP JP CQB1A1503Z 1 *
P24_Packing25 nsp LABEL , SPOTIFY(BK) BKE3, BKE2 CQB1A1458Z 1
P24_Packing25 nsp LABEL , SPOTIFY(SP) SPE2 CQB1A1459Z 1
P25_Packing27 nsp LABEL , HEOS PANEL E3 CQB1A1513Z 1 *
P26_Packing28 nsp LABEL , LICENSE CQB1A1520Z 1
P27_Packing29 nsp ORNAMENT , REAR PANEL CGX1A526Z 1 *
@ nsp TAPE , CLOTH 15MM CHS1A200 0.05
@ nsp WASHER , SHEET CNW1A064 1
@ nsp WASHER VNW2A028 2
@ nsp TAPE, HEMELON VHS1A032 2
@ nsp SUPPORT , PCB 31 CRE1A073 1
@ nsp CARD CABLE(1mm/13P/60mm/B TYPE)
CWC4F2A13B060B08SM
1
@ nsp LOCKER E2 CRE1A037 22
SCREW GROUP
S1 nsp SCREW , DOT BK VTBD3+10JFZR 6 *
S1 nsp SCREW , DOT SP VTBD3+10JFN 6 *
S2 nsp SCREW VTW3+8JR 23
S3 nsp SCREW VTB3+10JR 21
S4 nsp SCREW VTB3+8JR 36
S5 nsp SCREW SPECIAL VHD3A012R 27
S6 nsp SCREW VTW3+12JR 2
S7 nsp SCREW VTB3+6JR 11
S8 nsp SCREW VTB3+6FR 9
S9 nsp SCREW VTBD3+8JFZR 33
S10 nsp SCREW VTBD3+6FFZR 16
S11 nsp SCREW BK CTBD4+8JFZR 6
S11 nsp SCREW SP CTBD4+8JFN 6
S12 nsp SCREW , TRANS VHDR1A023R 4
S13 nsp SCREW, SPECIAL CHD1A109JFN 4
S14 nsp SCREW BK VTBD3+8JFZR 3
S14 nsp SCREW SP VTBD3+8JFN 3
52

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
