Denon AVR-X4300H Service Manual

4. AUDIO
4.1. AUDIO CHECK
No audio output
Check the ANALOG AUDIO BLOCK
Check the DIGITAL AUDIO BLOCK
Check the ADC BLOCK
Check the HDMI BLOCK
Check for other causes
Check the HDMI BLOCK
See "DIAGNOSTIC MODE"
Check the DIGITAL AUDIO BLOCK
CHECK 1 INPUT SURROUND MODE SOURCE
Audio output OK? ANALOG 2CH DIRECT ANALOG
CHECK 2 INPUT SURROUND MODE SOURCE
Audio output OK? COAX or OPT -
Legacy
(PCM or DolbyDigital or dts…)
CHECK 4 INPUT SURROUND MODE SOURCE
Audio output OK? HDMI -
Legacy
(PCM2ch or DolbyDigital or dts…)
CHECK 6 INPUT Connect
AVR's (connected in HDMI) audio out-
put OK?
HDMI This unit's HDMI OUT → Other AVR's HDMI IN
Setting SURROUND MODE SOURCE
CEC STANDBY - HBR audio(DolbyTrueHD or dtsHD MA)
CHECK 5 INPUT SURROUND MODE SOURCE
Audio output OK? HDMI -
HBR audio
(DolbyTrueHD or dtsHD MA)
CHECK 3 INPUT SURROUND MODE SOURCE
Audio output OK? ANALOG 2CH MULTICH STEREO ANALOG
YES
YES
YES
YES
YES
NO
NO
YES (DIGITAL AUDIO BLOCK is OK)
NO
NO
NO
NO
See "AUDIO CHECK PASS"
85
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
