F_HDMI
F_HDMI PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied. Part indicated b
y
"
@
" mark is not illustrated in the ex
p
loded vie
w
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC101 963236101380P I.C, HDMI BUFFER CVIAD8195ACPZ 1
Q1001 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C 1
Q1002 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C 1
RESISTOR GROUP
R1001 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1
R1002 nsp RES, CHIP(1005/5%/22Kohm) CRJ06IJ223T 1
R1003 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R1005 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1
R1006 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
R1007 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R1008 nsp RES, CHIP(1005/5%/2Kohm) CRJ06IJ202T 1
R1011 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1
RN101 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN102 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN103 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
RN104 nsp RES, CHIP(1005/5%/0ohm*2) CRJ062IJ0R0T 1
CAPACIITORS GROUP
C1001 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1002 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1003 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1004 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1005 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1006 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C1007 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1008 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1009 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1010 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1011 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1012 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1013 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1014 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1015 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1016 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
C1021 nsp CAP, CHIP(1005, 25V/0.01uF, X7R)_SAMSUNG CCUI1E103KCS 1
C1022 nsp CAP, CHIP(1005, 16V/0.1uF, X7R)_SAMSUNG CCUI1C104KCS 1
C1023 nsp CAP, CHIP(2012, 6.3V/10uF, X5R)_SAMSUNG CCUC0J106KCS 1
OTHER PARTS GROUP
BK101 nsp COVER , FRONT HDMI VMC1A483 1 *
BK541 nsp EARTH , HDMI CMC2A432 1
CN101 nsp WAFER, FFC(23PIN, 1mm STRAIGHT) CJP23GA333ZR 1
JK101 943643103000S JACK , HDMI(TYPE-A, SMT-19P, W/O FLANGE) CJJ9H022Z 1
L1001 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
L1002 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
50
