Page #138 background imageLoading...
Page #138 background image
3-5. TUNER STEP mode (E3 / E2 only) 3-6. Remote ID Setup Mode
3-5.1. Actions
This is a special mode for enabling reception STEP of the ANALOG TUNER to be changed.
3-5.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the "
5. TUNER FRQ SET
" using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to
conrm.
3-5.3. Displays
Start up this unit in TUNER STEP mode, select the desired option using the "
CURSOR
0
/
1
" button,
then enter using the "
ENTER
" button.
The following information is displayed in the following order.
(a) AM9 kHz / FM50 kHz is selected
L1
*TUNER FRQ Set
L2
< AM9/FM50 >
"
CURSOR
0
"
"
CURSOR
1
"
(b) AM10 kHz / FM200 kHz is selected
L2
< AM10/FM200 >
"
ENTER
"
(c) Press the power button to turn off the power.
(d) Press the power button to turn on the power.
3-6.1. Actions
This function allows only the desired AV receiver to be operated if multiple DENON AV receivers are
used in the same room.
3-6.2. Starting up
While holding down buttons "
ZONE3 SOURCE
" and "
STATUS
" simultaneously, press the power button
to turn on the power.
Select the "
6. REMOTE ID
" using the "
CURSOR
f
/
d
" button, then press the "
ENTER
" button to con-
rm.
3-6.3. Operations
(a) When Remote ID Setup mode is activated, the following message is displayed.
L1
L2
REMOTE ID ?
(b) Press the desired "
QUICK SELECT 1 - 4
" button.
Button Display
QUICK SELECT 1
L2
REMOTE ID 1
QUICK SELECT 2 L2
REMOTE ID 2
QUICK SELECT 3 L2
REMOTE ID 3
QUICK SELECT 4 L2
REMOTE ID 4
(c) Press the power button to turn off the power.
(d) Press the power button to turn on the power.
b
Only "
QUICK SELECT 1 - 4
" and the POWER button on the unit can be used in Remote ID Setup
Mode.
3-6.4. Setting the Remote control unit
(a) Press and hold the "
DEVICE MENU
" button for at least 3 seconds until the "
DEV.
", "
TU
" and "
AVR
"
indicators ash.
(b) Press "
MAIN
" button.
The "
DEV.
", "
TU
" and "
AVR
" indicators ash twice.
(c) Press the "
1
", "
2
", "
3
" or "
4
" button.
The "
DEV.
", "
TU
" and "
AVR
" indicators ash twice.
NOTE :
If the ID of the unit and remote control do not match, "
AVAMP
z
" appears on the display of the unit
when the remote control is used
(
z
: own remote control ID).
