Denon AVR-X4300H Service Manual

AMP
REF No. Part No. Part Name Remarks Q'ty New Ver
C7620 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7621 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7625 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7631 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1
C7632 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1
C7638 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7701 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1
C7702 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7704 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7706 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7707 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7712 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7719 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1
C7720 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7721 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7725 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7738 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7800 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C7801 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1
C7802 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7804 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7806 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7807 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7812 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7819 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1
C7820 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7821 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7825 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7831 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1
C7832 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1
C7838 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C7891 nsp CAP, ELECT(10V/330uF) CCEA1AH331T 1
C7901 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1
C7902 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7904 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7906 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7907 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1
C7912 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1
C7919 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1
C7920 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7921 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1
C7925 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C7938 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
OTHER PARTS GROUP
BK701 nsp BRACKET , PCB CMD1A569-V1 1
BK702 nsp BRACKET , PCB CMD1A569-V1 1
BN704 nsp WIRE ASS'Y, (7P, 2.0mm, 150mm, UL1569#26, 105) CWB7B007150AAC 1
BN781 nsp WIRE ASS'Y, (6P, 2.0mm, 280mm, UL1569#26, 105) CWB7B006280AAC 1
CN461 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/9PIN CJP09GI288ZY 1
CN462 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/7PIN CJP07GI288ZY 1
CN701 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/6PIN CJP06GI289ZY 1
CN702 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN CJP05GI289ZY 1
CN703 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/4PIN CJP04GI289ZY 1
CN707 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/5PIN CJP05GI289ZY 1
CN708 nsp LOCK-WAFER/STRAIGHT/2.5MM PITCH/6PIN CJP06GI289ZY 1
CN715 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN725 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN735 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN745 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN755 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN765 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN775 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN785 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
CN795 nsp WAFER (3PIN, AN, 2MM, JWT) CJP03GB48ZW 1
GND71 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
GND79 nsp PLATE , EARTH(TRONIC ELECTRONICS) CJT1A026 1
VR714 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR724 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR734 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR744 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR754 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR764 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR774 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR784 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
VR794 943161000920S RES,SEMI FIXED(1K, Vertical) CVN12E102B03T 1
49

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
