AMP

REF No. Part No. Part Name Remarks Q'ty New Ver

R7895 nsp RES, CARBON(1/5W,10Kohm,J) CRD20TJ103T 1

R7896 943252101080S PTC THEMISTORS, CHIP(75'C)

CRTDHPTF1608471P75T

R7900 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R7901 nsp RES, CARBON(1/5W,1.2Kohm,J) CRD20TJ122T 1

R7902 nsp RES, CARBON(1/5W,470Kohm,J) CRD20TJ474T 1

R7903 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R7904 nsp RES, CARBON(1/5W,1Kohm,J) CRD20TJ102T 1

R7905 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1

R7906 nsp RES, CHIP(1608/5%/390ohm) CRJ10DJ391T 1

R7907 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R7908 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1

R7910 nsp RES, CARBON(1/5W,110ohm,J) CRD20TJ111T 1

R7911 nsp RES, M-OXIDE FILM(1W/3.3Kohm) CRG1SANJ332RT 1

R7912 nsp RES, CARBON(1/5W,33Kohm,J) CRD20TJ333T 1

R7914 nsp RES , METAL(1/2W, 27k OHM) CRG12SANJ273T 1

R7916 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1

R7917 nsp RES, CHIP(1608/5%/1.2Kohm) CRJ10DJ122T 1

R7918 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1

R7919 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1

R7920 nsp RES, M-OXIDE FILM(2W/12Kohm) CRG2SANJ123RT 1

R7921 nsp RES, M-OXIDE FILM(1W/270ohm) CRG1SANJ271RT 1

R7924 nsp RES, CHIP(1608/5%/2.7Kohm) CRJ10DJ272T 1

R7925 nsp RES, CHIP(1608/5%/470ohm) CRJ10DJ471T 1

R7926 nsp RES, CHIP(1608/5%/560ohm) CRJ10DJ561T 1

R7929 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 1

R7930 943124500240S RES, M-OXIDE FILM(1W/22ohm) CRG1SANJ220RT 1

R7931 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1

R7932 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1

R7933 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1

R7934 943124500050S RES, M-OXIDE FILM(2W/0.47ohm) CRG2SANJR47RT 1

R7935 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R7936 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R7937 nsp RES, CHIP(1608/5%/680Kohm) CRJ10DJ684T 1

R7938 943252101070S PTC THEMISTORS, CHIP(115'C)

CRTDHPTF1608471P115T

R7939 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R7940 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R7941 nsp RES, CHIP(1608/5%/5.6Kohm) CRJ10DJ562T 1

R7943 nsp RES, CARBON(1/5W,47Kohm,J) CRD20TJ473T 1

R7944 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1

R7945 nsp RES, CARBON(1/5W,22Kohm,J) CRD20TJ223T 1

CAPACIITORS GROUP

C7001 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1

C7011 nsp CAP, ELECT(10V/330uF) CCEA1AH331T 1

C7012 nsp CAP, ELECT(10V/330uF) CCEA1AH331T 1

C7013 nsp CAP, ELECT(10V/47uF) CCEA1AH470T 1

C7101 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7102 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7104 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7106 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7107 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7112 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7119 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1

C7120 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7121 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7125 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7131 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7132 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7138 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C7201 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7202 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7204 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7206 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7207 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7212 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7219 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1

C7220 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7221 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7225 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7231 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7232 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7238 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C7301 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7302 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7304 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7306 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7307 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7312 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7319 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1

C7320 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7321 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7325 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7331 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7332 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C7338 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C7401 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7402 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7404 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7406 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7407 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7412 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7419 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1

C7420 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7421 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7425 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7438 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C7501 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7502 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7504 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7506 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7507 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7512 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7519 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1

C7520 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7521 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7525 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7538 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C7601 00D2544583971 CAP , ELEC(ELNA ROB SERIES, 47uF/50V) CCEA1HROB470T 1

C7602 nsp EOL item CAP, PE-FILM(100V/470pF/J) CCME2A471JR11T 1

C7604 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7606 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *

C7607 nsp CAP, MYLAR(50V/2200pF/J) HCQI1H222JZT 1

C7612 nsp EOL item CAP, PE-FILM(100V/220pF/J) CCME2A221JR11T 1

C7619 943132100720S CAP, CHIP(2012, 200V/150pF, C0G)_SAMWHA CCUC2D151JAH 1
