4.2. Power AMP (AMP PCB)
No audio output.
Protection is activated.
Is the power transistor open or short circuited?
2SB1647 / 2SD2560
Is the emitter resistor of the power transistor
open?
0.47 Ω
Is the base resistor of the power transistor open?
22 Ω
Is the trimmer potentiometer between the base
of the power transistor open?
1 k Ω
Are any other transistors faulty?
Are any other resistors faulty?
Turn on the power and, check that the voltage of each part is correct and that there is an idling cur-
rent.
Replace the power transistor.
Replace the transistor.
Replace the resistor.
Replace the emitter resistor.
Replace the base resistor.
Replace the trimmer potentiometers.
NO
NO
NO
NO
NO
NO
YES
Check the CPU.
4.3. Analog audio
No audio output.
Are the CN64C 4-7 pins in the SIDE CNT circuit
board receiving ± 7V?
Is there an audio signal in AMP PCB CN461/
CN462?
Reconnect the connectors correctly.
If the malfunctioning channel and function can be identied, check the corresponding signal path.
Repair the ± 7 V power supply.
Repair the power amplier.
Is serial data for electronic volume transmitted to
SIDE CNT PCB [CN23C 4, 5 pin] and FRONT CNT
PCB [CN26C 14, 15 pin]?
YES
NO
YES
YES
YES
YES
YES
YES NO
YES
NO
YES
