Denon AVR-X4300H Service Manual

FRONT CNT
REF No. Part No. Part Name Remarks Q'ty New Ver
C3143 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3144 nsp CAP, CHIP(2012, 50V/680pF, MURATA GRM21)
CCUMUC1H681JAM
1
C3147 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3148 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3149 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3150 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3153 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3154 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3155 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3156 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1
C3171 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3172 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3173 943132100710S CAP, CHIP(3216, 16V/4.7uF, Y5V)_SAMSUNG CCUP1C475ZFS 1
C3176 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C3177 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C3178 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3179 nsp CAP, CHIP(2012, 50V/470pF, MURATA GRM21)
CCUMUC1H471JAM
1
C3180 943132100710S CAP, CHIP(3216, 16V/4.7uF, Y5V)_SAMSUNG CCUP1C475ZFS 1
C3183 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C3184 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C3201 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3202 00D2544577958 CAP, ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C3203 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3204 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3205 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3206 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3207 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3208 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3209 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3210 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3211 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3212 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3301 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3302 00D2544577958 CAP, ELECT(16V/220uF),ELNA/RA3 CCEA1CRA3221T 1
C3303 nsp CAP, ELECT(100V/1uF),85'C Black CCEA2AH1R0T 1
C3304 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3305 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3306 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3307 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3308 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3309 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3310 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3311 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C3312 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C3313 nsp CAP, ELECT(16V/470uF) CCEA1CH471T 1
C9801 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C9802 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C9803 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C9804 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C9806 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1
C9809 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C9810 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C9811 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
OTHER PARTS GROUP
BD981 nsp FERRITE CHIP BEAD(1608/60R,CB03YTYH600) CLZ9R005V 1
BK3001 nsp BRACKET , PCB CMD1A629 1
BN25D nsp PIN SOCKET (25P,1.25mm,ANGLE, B-TO-B) CJP25HJ282Z 1
BN961 nsp WAFER, FFC(13P-1.25mm, STRAIGHT) CJP13GA115ZY 1
CN21A nsp PINHEADER(15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z 1
CN21B nsp WAFER, FFC(21P-1.25mm, STRAIGHT) CJP19GI281Z 1
CN24A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN24C nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP27GI281Z 1
CN25A nsp PIN HEADER (27P,1.25mm,STRAIGHT,B-TO-B) CJP25GI281Z 1
CN26A nsp PINHEADER(15P,1.25mm,STRAIGHT,B-TO-B) CJP15GI281Z 1
CN26C nsp WAFER, FFC(23P-1.25mm, STRAIGHT) CJP21GI281Z 1
TU901 943183100680S TUNER , FM(SCREW : F TYPE), AM , SI4730-D60 E3 CNVYST990-A9U2 1
TU901 943183100640S TUNER , RDS , FM(PAL TYPE) , AM , SI4731-D60 E2 CNVYST990-D8E2 1
TU901 943183100500S TUNER , FM(PAL TYPE) , AM , SI4730-D60 JP CNVYST990-A2J1 1
36

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
