SPK

REF No. Part No. Part Name Remarks Q'ty New Ver

R9248 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1

R9249 nsp RES, CHIP(1608/5%/470Kohm) CRJ10DJ474T 1

R9250 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9251 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R9323 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R9324 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R9325 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R9400 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T 1

R9402 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9403 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9404 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9405 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R9406 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1

R9410 nsp RES, CHIP(3216/5%/0ohm) CRJ14CJ0R0T 1

R9412 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9413 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9414 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1

R9415 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R9416 nsp RES, CHIP(1608/5%/47ohm) CRJ10DJ470T 1

R9711 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1

R9712 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1

R9713 nsp RES, M-OXIDE FILM(1W/1Kohm) CRG1SANJ102RT 1

R9727 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9905 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9906 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9907 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9908 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9909 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R9910 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1

R9911 nsp RES, CHIP(1608/5%/330Kohm) CRJ10DJ334T 1

R9912 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9913 nsp RES, CHIP(1608/5%/3.3Kohm) CRJ10DJ332T 1

R9914 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R9915 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R9917 943129501040S RES , CEMENT (5W, 0.01 OHM, 5% SMALL SIZE) CRF5EJR01HS 1

CAPACIITORS GROUP

C9211 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9212 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9213 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9214 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9215 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9216 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9217 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9218 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9219 nsp CAP, MYLAR(50V/0.047uF/J) HCQI1H473JZT 1

C9221 nsp CAP, ELECT(50V/100uF) CCEA1HH101T 1

C9250 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9251 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C9301 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1

C9303 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C9306 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9309 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1

C9311 943134010600S CAP, ELECT(16V/3300uF) CCEA1CH332E 1

C9312 943134010600S CAP, ELECT(16V/3300uF) CCEA1CH332E 1

C9315 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9316 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9317 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C9318 nsp CAP, ELECT(100V/10uF) CCEA2AH100T 1

C9321 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1

C9322 943134010620S CAP, ELECT(25V/4700uF) CCEA1EH472E 1

C9331 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9332 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9333 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9334 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9335 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9336 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9337 nsp CAP, MYLAR(50V/0.1uF/J) HCQI1H104JZT 1

C9407 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9417 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9531 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9532 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9533 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9534 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9535 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9536 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9537 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9538 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9539 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9540 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9541 nsp CAP, MYLAR(50V/0.01uF/J) HCQI1H103JZT 1

C9631 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9632 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9633 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9634 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9635 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9636 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9637 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9638 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9639 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9640 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9641 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9703 90M-OF100490R CAP, METAL PE FILM(250V/0.1uF) KCME2E104JP04T 1

C9705 134050110003S CAP, ELECT(71V/15000uF),35*58L,NICHICON

CCET71VLKS153NZ

C9706 134050110003S CAP, ELECT(71V/15000uF),35*58L,NICHICON

CCET71VLKS153NZ

C9708 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C9727 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C9905 943134003030S CAP, ELECT(100V/1uF),105'C CCEA2AH1R0TS 1

C9906 943134003030S CAP, ELECT(100V/1uF),105'C CCEA2AH1R0TS 1

C9909 943134003030S CAP, ELECT(100V/1uF),105'C CCEA2AH1R0TS 1

C9914 nsp CAP, ELECT(16V/100uF) CCEA1CH101T 1

C9917 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C9918 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C9919 nsp CAP, CHIP(1608, 50V/10pF, C0G)_SAMSUNG CCUS1H100JAS 1

C9920 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

OTHER PARTS GROUP

BK901 nsp PLATE , MAIN PCB VMC2A424 1

BK902 nsp PLATE , MAIN PCB VMC2A424 1

BN701 nsp WIRE ASS'Y, (6P, 2.5mm, 280mm, UL1569#20, 105) CWB7E0062803D 1

BN702 nsp WIRE ASS'Y, (5P, 2.5mm, 150mm, UL1569#20, 105) CWB7E0051503D 1

BN703 nsp WIRE ASS'Y, (4P, 2.5mm, 170mm, UL1569#20, 105) CWB7E0041703D 1

BN706 nsp WIRE ASS'Y, (3P, 2.0mm, 500mm, UL1569#24, 105 ) CWB7C003500HC 1

BN707 nsp WIRE ASS'Y, (5P, 2.5mm, 550mm, UL1569#20, 105) CWB7EZ055503D 1

BN708 nsp WIRE ASS'Y, (6P, 2.5mm, 650mm, UL1569#20, 105) CWB7EZ066503D 1
