DIGITAL

REF No. Part No. Part Name Remarks Q'ty New Ver

Q1902 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1903 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1906 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q1907 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1908 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1909 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q1910 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1911 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1912 963212500030S T.R, ISA1530AC1 CVTISA1530AC1 1

Q1913 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1914 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1915 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1916 943214500020S T.R,2SC3052 CVT2SC3052 1

Q1922 943214500020S T.R,2SC3052 CVT2SC3052 1

Q2001 213850009503S T.R , 2SC4617EBTLR(NPN,SOT-416, SMALL SIGNAL, ROHM

CVT2SC4617EBTLR

Q2002 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1

Q2003 963216500060S T.R,RT1N144C(10K-47K) CVTRT1N144C 1

Q3841 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3842 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3851 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3852 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3861 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3862 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3871 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3872 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3941 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3942 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3951 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3952 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3961 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q3962 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5001 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5002 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5003 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5004 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5005 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

Q5006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C 1

IC523 963239002150S I.C , OCTAL BUFFER/DRIVER

CVISN74LVC244APWR

RESISTOR GROUP

R1009 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1011 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1024 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1

R1025 nsp RES, CHIP(1005/5%/0ohm) CRJ06IJ0R0T 1

R1111 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1112 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1114 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1115 nsp RES, CHIP(1608/1%/14Kohm) CRJ10DF1402T 1

R1116 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1121 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1122 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1124 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1125 nsp RES, CHIP(1608/1%/33.2Kohm) CRJ10DF3322T 1

R1126 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1131 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1132 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1134 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1135 nsp RES, CHIP(1608/1%/33.2Kohm) CRJ10DF3322T 1

R1136 nsp RES, CHIP(1608/1%/390ohm) CRJ10DF3900T 1

R1171 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1172 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1174 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1175 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1

R1176 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1181 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1182 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1184 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1185 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1

R1186 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1191 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1192 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1194 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1195 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1

R1196 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1201 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1202 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1204 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1205 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1

R1206 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1211 nsp RES, CHIP(1608/5%/33ohm) CRJ10DJ330T 1

R1212 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R1214 nsp RES, CHIP(1608/1%/10Kohm) CRJ10DF1002T 1

R1215 nsp RES, CHIP(1608/1%/4.7Kohm) CRJ10DF4701T 1

R1216 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1226 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1227 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1228 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1229 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1230 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R1231 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1232 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1233 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1234 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1236 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1237 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1238 nsp RES, CHIP(1005/5%/4.7Kohm) CRJ06IJ472T 1

R1239 nsp RES, CHIP(1005/5%/47Kohm) CRJ06IJ473T 1

R1240 nsp RES, CHIP(1005/5%/100Kohm) CRJ06IJ104T 1

R1241 nsp RES, CHIP(1005/5%/100ohm) CRJ06IJ101T 1

R1256 nsp RES, CHIP(1005/5%/330ohm) CRJ06IJ331T 1

R1258 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1259 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1312 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1313 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1322 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1323 nsp RES, CHIP(1005/5%/27Kohm) CRJ06IJ273T 1

R1331 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1333 nsp RES, CHIP(1005/5%/33Kohm) CRJ06IJ333T 1

R1342 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1343 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1352 nsp RES, CHIP(1005/5%/1Kohm) CRJ06IJ102T 1

R1353 nsp RES, CHIP(1005/5%/27Kohm) CRJ06IJ273T 1

R1362 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1

R1363 nsp RES, CHIP(1005/5%/10Kohm) CRJ06IJ103T 1
