FRONT

REF No. Part No. Part Name Remarks Q'ty New Ver

R6605 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R6607 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R6613 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R6614 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R6632 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

R6701 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R6703 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R6704 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R6705 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R6706 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1

R6707 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R6711 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1

R6718 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R6719 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1

R6720 nsp RES, CHIP(1608/5%/33Kohm) CRJ10DJ333T 1

R6721 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R6723 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1

R6726 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1

R6734 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1

R6735 nsp RES, CHIP(1608/5%/0ohm) CRJ10DJ0R0T 1

CAPACIITORS GROUP

C6021 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1

C6024 nsp CAP , ELECT(63V/100uF) CCEA1JH101E 1

C6025 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C6027 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C6034 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6071 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C6072 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C6073 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C6081 nsp CAP, CHIP(2012, 50V/0.1uF, X7R)_SAMSUNG CCUC1H104KCS 1

C6082 nsp CAP, ELECT(6.3V/470uF) CCEA0JH471T 1

C6083 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1

C6084 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1

C6113 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6114 nsp CAP, ELECT(16V/47uF) CCEA1CH470T 1

C6351 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1

C6352 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1

C6417 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1

C6423 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1

C6424 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1

C6501 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C6502 nsp CAP, CHIP(1608, 50V/1000pF, X7R)_SAMSUNG CCUS1H102KCS 1

C6503 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6512 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6523 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1

C6601 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1

C6603 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C6604 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1

C6623 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6624 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6691 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6693 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6702 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

C6703 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C6704 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1

C6706 943134502680M CAP , ELECT(10uF/63V ) CCEA1JH100T 1

C6712 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1

C6719 nsp CAP, ELECT(16V/100uF)-S CCEA1CKS101T 1

C6720 nsp CAP, CHIP(1608, 50V/33pF, C0G)_SAMSUNG CCUS1H330JAS 1

C6726 nsp CAP, CHIP(1608, 50V/0.047uF, X7R)_SAMSUNG CCUS1H473KCS 1

C6731 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C6732 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 1

C6733 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1

C6735 nsp CAP, CHIP(1608, 50V/100pF, C0G)_SAMSUNG CCUS1H101JAS 1

C6753 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1

OTHER PARTS GROUP

BK602 nsp BRACKET , PCB CMD1A569-V1 1

BK603 nsp BRACKET , PCB CMD1A569-V1 1

BK604 nsp BRACKET , FIP CMD1A572-V1 1

BK605 nsp BRACKET , FIP CMD1A572-V1 1

BK606 nsp BRACKET , PCB CMD1A569-V1 1

CN602 nsp WAFER/ANGLE/2.5mm/07P CJP07GB03ZY 1

CN605A nsp WAFER , BD TO BD 2.0MM(SOKET) CJP05GB280ZK 1

CN605B nsp WAFER , BD TO BD 2.0MM(PLUG) CJP05GA279ZK 1

CN69A nsp WAFER, FFC(40P-1mm,ANGLE) CJP40GB284ZN 1

! F6001 943652500600S FUSE(932Series, 250V/200mA) CBA2J0200TLUBT 1

FL601 17201001300AS VFD , FUTABA , 17-BT-040GINK , CIG-TYPE CFL17BT040GINK 1

JK605 90M-YT004500R JACK, PHONES(6.35mm,SILVER) CJJ2E026Z 1

JK606 943643102980S JACK, 3P(B/B/B)with S/W, SILVER, VERTICAL CJJ4S051Z 1

JK607 943643102400S JACK, MIC(3.5mm, MONO, STRAIGHT) CJJ1D006Z 1

JW601 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1

L6001 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6002 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6003 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6004 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6005 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6006 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6007 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6008 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6009 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6010 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6501 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

L6601 nsp CHIP BEAD(600R, 1808, 0.5A) HLZ9Z008Z 1

RC601 943262100140S SENSOR, REMOTE(37.9KHz) CRVHM238RT12 1

SW601 00D9430004402 SW , TACT CST1A012ZT 1

SW602 00D9430004402 SW , TACT

CST1A012ZT 1

SW603 00D9430004402 SW , TACT CST1A012ZT 1

SW604 00D9430004402 SW , TACT CST1A012ZT 1

SW605 00D9430004402 SW , TACT CST1A012ZT 1

SW606 00D9430004402 SW , TACT CST1A012ZT 1

SW611 00D9430004402 SW , TACT CST1A012ZT 1

SW612 00D9430004402 SW , TACT CST1A012ZT 1

SW613 00D9430004402 SW , TACT CST1A012ZT 1

SW614 00D9430004402 SW , TACT CST1A012ZT 1

SW615 00D9430004402 SW , TACT CST1A012ZT 1

SW616 00D9430004402 SW , TACT CST1A012ZT 1

SW617 00D9430004402 SW , TACT CST1A012ZT 1

SW621 00D9430004402 SW , TACT CST1A012ZT 1

SW622 00D9430004402 SW , TACT CST1A012ZT 1

SW623 00D9430004402 SW , TACT CST1A012ZT 1

SW624 00D9430004402 SW , TACT CST1A012ZT 1

SW625 00D9430004402 SW , TACT CST1A012ZT 1

SW626 00D9430004402 SW , TACT CST1A012ZT 1

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g

Denon AVR-X4300H Service Manual
