Denon AVR-X4300H Service Manual

INPUT
REF No. Part No. Part Name Remarks Q'ty New Ver
C4902 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C4935 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C4936 nsp CAP, ELECT(35V/470uF) CCEA1VH471T 1 *
C4937 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C4938 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C4939 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C4940 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C6802 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C6803 nsp CAP, ELECT(10V/220uF)-S CCEA1AKS221T 1
C8509 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8510 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8703 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8704 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8709 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8710 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8723 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8724 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8727 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8728 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8729 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8730 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8739 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8740 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8743 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8744 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8747 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8748 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8749 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8750 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8759 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8768 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8769 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8772 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8777 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8778 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8779 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8780 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8781 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8787 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8788 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8791 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8796 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8797 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8798 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8799 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8803 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8807 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8809 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8819 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8820 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8825 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8826 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8829 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8834 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8835 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8836 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8837 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8838 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8849 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C8869 nsp CAP, ELECT(50V/0.1uF) CCEA1HH0R1T 1
C8913 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8914 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8917 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8918 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8919 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8920 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8929 nsp CAP, ELECT(50V/0.47uF) CCEA1HHR47T 1
C8963 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8964 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8967 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8968 nsp CAP, ELECT(50V/22uF) CCEA1HH220T 1
C8969 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8970 nsp CAP, CHIP(1608, 50V/330pF, C0G)_SAMSUNG CCUS1H331JAS 1
C8979 nsp CAP, ELECT(50V/0.47uF) CCEA1HHR47T 1
C8991 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8992 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8993 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8994 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8995 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
C8996 nsp CAP, CHIP(1608, 50V/0.1uF, X7R)_SAMSUNG CCUS1H104KCS 1
C8997 nsp CAP, CHIP(1608, 50V/0.01uF, X7R)_SAMSUNG CCUS1H103KCS 1
OTHER PARTS GROUP
BK469 nsp EARTH , INPUT VMC1A440 1
BK608 nsp EARTH , USB CMC1A432 1
BN23C nsp PIN SOCKET (19P,1.25mm,ANGLE, B-TO-B) CJP19HJ282Z 1
BN24C nsp PIN SOCKET (27P,1.25mm,ANGLE,B-TO-B) CJP27HJ282Z 1
BN26C nsp PIN SOCKET (21P,1.25mm,ANGLE, B-TO-B) CJP21HJ282Z 1
BN321 nsp WIRE ASS'Y, (5P, 2.0mm, 400mm, UL2725#24/#28)USB CWB8A005400HC 1 *
BN322A nsp WIRE ASS'Y, (3P,2.0mm,100mm, BD IN TO BD IN)
CWB1B003100CC001
1*
BN323 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
BN461 nsp WIRE ASS'Y, (9P, 2.0mm, 450mm, UL1569#26, 105) CWB7B009450HC 1
BN462 nsp WIRE ASS'Y, (7P, 2.0mm, 500mm, UL1569#26, 105) CWB7BZ07500HC 1
BN64C nsp PIN SOCKET (11P,1.25mm,ANGLE,B-TO-B) CJP11HJ282Z 1
CN706 nsp LOCK-WAFER/STRAIGHT/2MM PITCH/3PIN CJP03GI288ZY 1
JK461 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK462 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK463 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK608 943643103420S JACK, USB ANGLE(BLACK, 1.5A) CJJ9X032Z 1 *
JK871 643010079004S JACK, 4P(W/R,W/B),SEPA-GND, SILVER CJJ4P077Z 1
JK872 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK873 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
JK875 943643010160S JACK, 1P(BK),SEPA-GND, SILVER CJJ4M046U 1
JK891 943643101570S JACK, 4P(W/R,W/R),SEPA-GND CJJ4P048U 1
L4661 00D9430193601 COIL, TOROIDAL E2 CLU9S004Z 1
L4662 00D9430193601 COIL, TOROIDAL E2 CLU9S004Z 1
L6831 nsp FERRITE CHIP BEAD(2012/220R)
CLZBLM21PG221SN1
1
RY871 943682000810S RELAY,BC3-12H,DC12V,2C2P CSL4A016ZU 1
43

Denon AVR-X4300H Specifications

General

Display	-
Product color	Black
Audio decoders	DTS Neo:X, DTS-HD Master Audio, Dolby Pro Logic IIz, Dolby Surround, Dolby TrueHD
Audio amplifier	Yes
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Receiver type	Surround
Audio output channels	11.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
HDMI in	8
Remote (IR) input	1
Composite video in	4
Digital audio coaxial in	2
Headphone connectivity	3.5 mm
Number of HDMI outputs	3
Multichannel audio output type	RCA
Supported video modes	1080p, 2160p
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Power consumption (standby)	0.1 W
Power consumption (typical)	710 W
Card reader integrated	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	236 mm
Weight	13500 g
