Denon AVR-X5200W Service Manual

The circuit around CX870 is faulty.
YES
YES
YES
YES
YES
Can an output voltage (3.3V) to
U611(DC-DC Conv.) be conrmed?
Can an output voltage (1.2V) to U608
be conrmed?
Can an output voltage (1.9V) to U903
be conrmed?
Are the versions of the Ethernet SBL and IMG displayed in Version
Check Mode?
Can a voltage (5V) be conrmed between pin 2 and pin 5 of
N6502?
Is D5V_POWER (U5001 uCOM 85pin)
"Hi" ?
Is E_POWER4 (U5001 uCOM 56pin)
"Hi" ?
Is E_POWER2 (U5001 uCOM 54pin)
"Hi" ?
The circuit of D5V_POWER between
U5001 and U611 are faulty.
The circuit of E_POWER4 between
U608 and U5001 are faulty.
The circuit of E_POWER2 between
U5001 and U903 are faulty.
The circuit around U5001(DC-DC.
Conv.) is faulty.
The circuit around U608(DC-DC.
Conv.) is faulty.
The circuit around U903(DC-DC.
Conv.) is faulty.
The Ethernet software is faulty.
The circuit between the AC inlet and N6502
is faulty. Check the SMPS PCB.
NO
NO
NO
NO
NO
NO
NO
NO
YES
YES
YES
108

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
