Denon AVR-X5200W Service Manual

YES
YES
YES
YES
YES
YES
The circuit around Bluetooth Module (iBT-06-02S) or CX870 is faulty.
Can a voltage (5V) be conrmed between pin 1 and pin 4 of N903 on
DIGITAL PCB?
Can a voltage (5V) be conrmed pin 10 of N901 on Bluetooth PCB?
Can a voltage (3.3V) be conrmed pin 6 of N901 on Bluetooth PCB?
Can a voltage (3.6V) be conrmed pin 1 of U1 on Bluetooth PCB?
Can a waveform (32.768kHz) be conrmed pin 4 of U2 on Bluetooth
PCB?
Is 4pin(LDO_ON) of Bluetooth PCB N901 "Hi"?
The circuit between the AC inlet and N903 is faulty.
Check the SMPS PCB.
The circuit between N903 of the DIGITAL PCB and
N1 of the Bluetooth PCB are faulty of wire or board.
The circuit around U1901 of the DIGITAL PCB is
faulty.
The circuit around U1 is faulty.
The oscillation circuit including U2 is faulty.
The circuit between CX870 and N901 of the LDO_
ON are faulty.
NO
NO
NO
NO
NO
NO
5.2. Cannot connect to the Bluetooth
109

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
