Denon AVR-X5200W Service Manual

FRONT SPK
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
C6227,6228 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C6229,6230 13405013340AS CE04W1E471MT(KR3) 13405013340AS 2
C6235,6236 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C6403 nsp CK73B1E104KT +1608 00D2570516954 1
C6404 nsp CK73B1H102KT +1608 00D2570509929 1
C6405 nsp CK73B1H222KT +1608 00D2570509990 1
C6406 nsp CK73B1E104KT +1608 00D2570516954 1
C6407 nsp CK73B1H102KT +1608 00D2570509929 1
C6408 nsp CK73B1H222KT +1608 00D2570509990 1
C6409 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C6410-6412 nsp CK73B1E104KT +1608 00D2570516954 3
C6413,6414 nsp C1608X7R1H104K 00MDK9610430Y 2
C6416 13405014940AS CE04W1J101MT(KR3) 13405014940AS 1
C6417 nsp CK73B1E104KT +1608 00D2570516954 1
C6418-6420 nsp C1608X7R1H104K 00MDK9610430Y 3
C6421 13405014440AS CE04W1H101MT(KR3) 13405014440AS 1
C6422 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C6423 nsp CK73B1E104KT +1608 00D2570516954 1
C6427 nsp C1608X7R1H104K 00MDK9610430Y 1
C6431 nsp CK73B1H102KT +1608 00D2570509929 1
C6433 nsp CK73B1E104KT +1608 00D2570516954 1
C6434 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C6436-6439 nsp CK73B1E104KT +1608 00D2570516954 4
C6443,6444 nsp CK73B1E104KT +1608 00D2570516954 2
C6445-6447 13405014840AS CE04W1J100MT(KR3) 13405014840AS 3
C6448 nsp CC73CH1H330JT +1608 00D2570504940 1
C6452 13405012940AS CE04W1C101MT(KR3) 13405012940AS 1
C6453 nsp CC73CH1H101JT +1608 00D2570506951 1
C6454-6457 13405014840AS CE04W1J100MT(KR3) 13405014840AS 4
C6459,6460 nsp CC73CH1H331JT +1608 00D2570507976 2
C6461-6464 nsp CK73B1E104KT +1608 00D2570516954 4
C6465 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C6466,6467 nsp RM73B--0R0KT +1608 00D2472018903 2
C6468 nsp CK73B1E104KT +1608 00D2570516954 1
C6469 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C6470-6475 nsp RM73B--0R0KT +1608 00D2472018903 6
OTHER PARTS GROUP
B6001 nsp 1P 130mm SIN-SIN 61205049500AS 1
B6006,6007 nsp GND TERMINAL FOR PCB 00MYL01010241 2
B6020 nsp GND TERMINAL FOR PCB 00MYL01010241 1
B6402 nsp M3 SCREW TERMINAL 00D2051034007 1
B6412 nsp GND TERMINAL FOR PCB 00MYL01010241 1
! F0010 652010025070S L=20mm 250V/T10
A
652010025070S 1 *
! F0020 652010025070S L=20mm 250V/T10
A
652010025070S 1 *
! F6201 65205003444AS FUSE
(
SCT2.5A
)
65205003444AS 1 *
! F6202-6204 65205003443AS FUSE
(
SCT2A
)
65205003443AS 3 *
! F6206 65205003540AS FUSE
(
SCT250MA
)
65205003540AS 1 *
! F6401 65205003540AS FUSE
(
SCT250MA
)
65205003540AS 1 *
H0031,0032 nsp FUSE CLIP(TAPE) 00D2020040909 2
H0041,0042 nsp FUSE CLIP(TAPE) 00D2020040909 2
K6001-6011 64601006000AS 2P SP TERMINAL 64601006000AS 11 *
K6401 64301017400AS H/P JACK(PJ-612AG-7)-AU 64301017400AS 1
K6402 64301027400AS MINI JACK(PJ-3610) 64301027400AS 1 *
K6403 64301019701AS 3P PIN JACK(MSP-303H)-AU-BK 64301019701AS 1 *
N6001-6009 nsp B5B-EH 00MYP06010450 9
N6010 nsp B11B-PH-K-S (LF)(SN) 00MYJ06006310 1
N6011 nsp B12B-PH-K-S (LF)(SN) 00MYJ06006320 1
N6012 nsp B9P-VH 00MYP06010990 1
N6013 nsp 33P FFC BASE 00D2050736005 1
N6201 nsp B5B-EH 00MYP06010450 1
N6202 nsp 7P 130mm EH-SCN 61205062800AS 1 *
N6203 nsp 3P 130mm PH-SAN 61205049902AS 1 *
N6204 nsp 6P 130mm PH-SAN 61205062700AS 1 *
N6401 nsp S7B-EH 00MYP06003960 1
N6402 nsp 9P PLUG(C125Z1) 645010067014S 1
N6403 nsp 9P SOCKET(C125Z2) 645010068017S 1
N6405 nsp 40FMN-STRK-A(LF)(SN) 645010075008S 1
N6804 nsp 3P 60mm SCN-SCN 61205062600AS 1 *
! S6001 68201003000AS RELAY
(
FTR-F1CL012R
)
68201003000AS 1
! S6002-6011 682010020007S G5PA-28-MC DC12 682010020007S 10
S6401-6420 00D2125611903 TACT SWITCH(TAPE H5) 00D2125611903 20
S6421 663010006000S ROT.ENCODER(EC16B24T01D4ZZZ) 663010006000S 1
S6422 66301001300AS ROT.ENCODER(EC16B12SAAD4ZZZ) 66301001300AS 1 *
Z6003,6004 nsp STYLE PIN 00D2050452017 2
Z6008-6010 nsp STYLE PIN 00D2050452017 3
Z6012 nsp STYLE PIN 00D2050452017 1
Z6402 17201001300AS FLD(17-BT-40GINK) 17201001300AS 1
Z6403,6404 nsp RUBBER SHEET (30X7X7) 47101008700AD 2 *
Z6411,6412 nsp STYLE PIN 00D2050452017 2
3

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
